Siemens 6RA7086-6KS22

05.05 Connectors and binectors
SIEMENS AG 6RX1700-0AD76 12-21
SIMOREG DC Master Operating Instructions
Connector Description Normalization Function
diag., Sheet
K9352
I component
16384
=
∧
100%
B185
K9353
Output PI controller before limitation
16384
=
∧
100%
B185
K9354
Output PI controller after limitation
16384
=
∧
100%
B185
K9355
Positive limit for the output of the PI controller
16384
=
∧
100%
B185
K9356
Positive limit for the output of the PI controller (K9355)
∗ -1
16384
=
∧
100%
B185
K9357
Negative limit for the output of the PI controller
16384
=
∧
100%
B185
Technology software S00: PI controller 7 [SW 1.8 and later] FB266
K9360
Input quantity filtered
16384
=
∧
100%
B186
K9361
P component
16384
=
∧
100%
B186
K9362
I component
16384
=
∧
100%
B186
K9363
Output PI controller before limitation
16384
=
∧
100%
B186
K9364
Output PI controller after limitation
16384
=
∧
100%
B186
K9365
Positive limit for the output of the PI controller
16384
=
∧
100%
B186
K9366
Positive limit for the output of the PI controller (K9365)
∗ -1
16384
=
∧
100%
B186
K9367
Negative limit for the output of the PI controller
16384
=
∧
100%
B186
Technology software S00: PI controller 8 [SW 1.8 and later] FB267
K9370
Input quantity filtered
16384
=
∧
100%
B187
K9371
P component
16384
=
∧
100%
B187
K9372
I component
16384
=
∧
100%
B187
K9373
Output PI controller before limitation
16384
=
∧
100%
B187
K9374
Output PI controller after limitation
16384
=
∧
100%
B187
K9375
Positive limit for the output of the PI controller
16384
=
∧
100%
B187
K9376
Positive limit for the output of the PI controller (K9375)
∗ -1
16384
=
∧
100%
B187
K9377
Negative limit for the output of the PI controller
16384
=
∧
100%
B187
Technology software S00: PI controller 9 [SW 1.8 and later] FB268
K9380
Input quantity filtered
16384
=
∧
100%
B188
K9381
P component
16384
=
∧
100%
B188
K9382
I component
16384
=
∧
100%
B188
K9383
Output PI controller before limitation
16384
=
∧
100%
B188
K9384
Output PI controller after limitation
16384
=
∧
100%
B188
K9385
Positive limit for the output of the PI controller
16384
=
∧
100%
B188
K9386
Positive limit for the output of the PI controller (K9385)
∗ -1
16384
=
∧
100%
B188
K9387
Negative limit for the output of the PI controller
16384
=
∧
100%
B188
Technology software S00: PI controller 10 [SW 1.8 and later] FB269
K9390
Input quantity filtered
16384
=
∧
100%
B189
K9391
P component
16384
=
∧
100%
B189
K9392
I component
16384
=
∧
100%
B189
K9393
Output PI controller before limitation
16384
=
∧
100%
B189
K9394
Output PI controller after limitation
16384
=
∧
100%
B189
K9395
Positive limit for the output of the PI controller
16384
=
∧
100%
B189
K9396
Positive limit for the output of the PI controller (K9395)
∗ -1
16384
=
∧
100%
B189
K9397
Negative limit for the output of the PI controller
16384
=
∧
100%
B189
Technology software S00: Derivative/delay elements
K9400
Derivative/delay element 1 output [SW 1.8 and later] FB 270
16384
=
∧
100%
B156
K9401
Derivative/delay element 2 output [SW 1.8 and later] FB 271
16384
=
∧
100%
B156
