Connectors and binectors 05.05
12-22 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
Connector Description Normalization Function
diag., Sheet
K9402
Derivative/delay element 3 output [SW 1.8 and later] FB 272
16384
=
∧
100%
B156
K9403
Derivative/delay element 4 output [SW 1.8 and later] FB 273
16384
=
∧
100%
B156
K9404
Derivative/delay element 5 output [SW 1.8 and later] FB 274
16384
=
∧
100%
B157
K9405
Derivative/delay element 6 output [SW 1.8 and later] FB 275
16384
=
∧
100%
B157
K9406
Derivative/delay element 7 output [SW 1.8 and later] FB 276
16384
=
∧
100%
B157
K9407
Derivative/delay element 8 output [SW 1.8 and later] FB 277
16384
=
∧
100%
B157
K9408
Derivative/delay element 9 output [SW 1.8 and later] FB 278
16384
=
∧
100%
B158
K9409
Derivative/delay element 10 output [SW 1.8 and later] FB 279
16384
=
∧
100%
B158
Technology software S00: Characteristic blocks
K9410
Output characteristic block 4 [SW 1.8 and later] FB 280
16384
=
∧
100%
B160
K9411
Output characteristic block 5 [SW 1.8 and later] FB 281
16384
=
∧
100%
B160
K9412
Output characteristic block 6 [SW 1.8 and later] FB 282
16384
=
∧
100%
B160
K9413
Output characteristic block 7 [SW 1.8 and later] FB 283
16384
=
∧
100%
B160
K9414
Output characteristic block 8 [SW 1.8 and later] FB 284
16384
=
∧
100%
B160
K9415
Output characteristic block 9 [SW 1.8 and later] FB 285
16384
=
∧
100%
B160
Technology software S00: Multiplier
K9430
Output multiplier 5 [SW 1.8 and later] FB 290
16384
=
∧
100%
B130
K9431
Output multiplier 6 [SW 1.8 and later] FB 291
16384
=
∧
100%
B130
K9432
Output multiplier 7 [SW 1.8 and later] FB 292
16384
=
∧
100%
B130
K9433
Output multiplier 8 [SW 1.8 and later] FB 293
16384
=
∧
100%
B130
K9434
Output multiplier 9 [SW 1.8 and later] FB 294
16384
=
∧
100%
B130
K9435
Output multiplier 10 [SW 1.8 and later] FB 295
16384
=
∧
100%
B130
K9436
Output multiplier 11 [SW 1.8 and later] FB 296
16384
=
∧
100%
B130
K9437
Output multiplier 12 [SW 1.8 and later] FB 297
16384
=
∧
100%
B130
S00 technology software: Software counter
K9441
Minimum value for software counter [SW 1.9 and later] FB 89
1
=
∧
1
B196
K9442
Maximum value for software counter [SW 1.9 and later] FB 89
1
=
∧
1
B196
K9443
Setting value for software counter [SW 1.9 and later] FB 89
1
=
∧
1
B196
K9444
Start value for software counter [SW 1.9 and later] FB 89
1
=
∧
1
B196
K9445
Software counter output [SW 1.9 and later] FB 89
1
=
∧
1
B196
Technology software S00: Multiplexer
K9450
Output multiplexer 1 [SW 1.8 and later] FB 86
16384
=
∧
100%
B195
K9451
Output multiplexer 2 [SW 1.8 and later] FB 87
16384
=
∧
100%
B195
K9452
Output multiplexer 3 [SW 1.8 and later] FB 88
16384
=
∧
100%
B195
Technology software S00: Averagers
K9455
Output averager 1 [SW 1.8 and later] FB 16
16384
=
∧
100%
B139
K9456
Output averager 2 [SW 1.8 and later] FB 17
16384
=
∧
100%
B139
K9457
Output averager 3 [SW 1.8 and later] FB 18
16384
=
∧
100%
B139
K9458
Output averager 4 [SW 1.8 and later] FB 19
16384
=
∧
100%
B139
Technology software S00: Minimum selections, Maximum selections
K9460
Output Maximum selection 2 [SW 1.8 and later] FB 174
16384
=
∧
100%
B140
K9461
Output Maximum selection 3 [SW 1.8 and later] FB 175
16384
=
∧
100%
B140
K9462
Output Maximum selection 4 [SW 1.8 and later] FB 176
16384
=
∧
100%
B140
K9463
Output Minimum selection 2 [SW 1.8 and later] FB 177
16384
=
∧
100%
B140
