05.05 Connectors and binectors
SIEMENS AG 6RX1700-0AD76 12-23
SIMOREG DC Master Operating Instructions
Connector Description Normalization Function
diag., Sheet
K9464
Output Minimum selection 3 [SW 1.8 and later] FB 178
16384
=
∧
100%
B140
K9465
Output Minimum selection 4 [SW 1.8 and later] FB 179
16384
=
∧
100%
B140
Technology software S00: position fixed value, position actual value, positional deviation
KK9471
Position fixed value1 [SW 2.0 and later] FB 54
1
=
∧
1
B152
KK9472
Position fixed value2 [SW 2.0 and later] FB 54
1
=
∧
1
B152
KK9473
Position fixed value3 [SW 2.0 and later] FB 54
1
=
∧
1
B152
KK9474
Position fixed value4 [SW 2.0 and later] FB 54
1
=
∧
1
B152
KK9481
Position actual value 1 [SW 2.0 and later] FB 54
1
=
∧
1
B152
KK9482
Position actual value 2 [SW 2.0 and later] FB 54
1
=
∧
1
B152
KK9483
Positional deviation [SW 2.0 and later] FB 54
1
=
∧
1
B152
K9484
Positional deviation limited [SW 2.0 and later] FB 54
1
=
∧
1
B152
Technology software S00: root extractor
KK9485
Root extractor output [SW 2.0 and later] FB 58
16384
=
∧
100%
B153
S00 technology software: Adders / subtracters for double-word connectors
KK9490
Output of 1
st
adder / subtracter [SW 1.9 and later] FB 48
16384*65536
=
∧
100%
B151
K9491
Output of 1
st
adder / subtracter (limited) [SW 1.9 and later] FB 48
16384
=
∧
100%/65536
B151
KK9492
Output of 2
nd
adder / subtracter [SW 1.9 and later] FB 49
16384*65536
=
∧
100%
B151
K9493
Output of 2
nd
adder / subtracter (limited) [SW 1.9 and later] FB 49
16384
=
∧
100%/65536
B151
S00 technology software: Connector type converters
KK9498
Output of 1
st
connector type converter [SW 1.9 and later] FB 298
16384*65536
=
∧
100%
B151
KK9499
Output of 2
nd
connector type converter [SW 1.9 and later] FB 299
16384*65536
=
∧
100%
B151
Technology software S00: Fixed values [SW 1.8 and later]
K9501
Fixed value 1 (U099.01) [SW 1.8 and later]
16384
=
∧
100%
B110
K9502
Fixed value 2 (U099.02) [SW 1.8 and later]
16384
=
∧
100%
B110
K9503
Fixed value 3 (U099.03) [SW 1.8 and later]
16384
=
∧
100%
B110
K9504
Fixed value 4 (U099.04) [SW 1.8 and later]
16384
=
∧
100%
B110
K9505
Fixed value 5 (U099.05) [SW 1.8 and later]
16384
=
∧
100%
B110
K9506
Fixed value 6 (U099.06) [SW 1.8 and later]
16384
=
∧
100%
B110
K9507
Fixed value 7 (U099.07) [SW 1.8 and later]
16384
=
∧
100%
B110
K9508
Fixed value 8 (U099.08) [SW 1.8 and later]
16384
=
∧
100%
B110
K9509
Fixed value 9 (U099.09) [SW 1.8 and later]
16384
=
∧
100%
B110
K9510
Fixed value 10 (U099.10) [SW 1.8 and later]
16384
=
∧
100%
B110
K9511
Fixed value 11 (U099.11) [SW 1.8 and later]
16384
=
∧
100%
B110
K9512
Fixed value 12 (U099.12) [SW 1.8 and later]
16384
=
∧
100%
B110
K9513
Fixed value 13 (U099.13) [SW 1.8 and later]
16384
=
∧
100%
B110
K9514
Fixed value 14 (U099.14) [SW 1.8 and later]
16384
=
∧
100%
B110
K9515
Fixed value 15 (U099.15) [SW 1.8 and later]
16384
=
∧
100%
B110
K9516
Fixed value 16 (U099.16) [SW 1.8 and later]
16384
=
∧
100%
B110
K9517
Fixed value 17 (U099.17) [SW 1.8 and later]
16384
=
∧
100%
B110
K9518
Fixed value 18 (U099.18) [SW 1.8 and later]
16384
=
∧
100%
B110
K9519
Fixed value 19 (U099.19) [SW 1.8 and later]
16384
=
∧
100%
B110
K9520
Fixed value 20 (U099.20) [SW 1.8 and later]
16384
=
∧
100%
B110
K9521
Fixed value 21 (U099.21) [SW 1.8 and later]
16384
=
∧
100%
B110
K9522
Fixed value 22 (U099.22) [SW 1.8 and later]
16384
=
∧
100%
B110
K9523
Fixed value 23 (U099.23) [SW 1.8 and later]
16384
=
∧
100%
B110
