05.05 Connectors and binectors
SIEMENS AG 6RX1700-0AD76 12-37
SIMOREG DC Master Operating Instructions
Binector Name, description Function
diag., Sheet
B3906
Receive data from 1
st
CB/TB, word 9, bit 6 Z110
B3907
Receive data from 1
st
CB/TB, word 9, bit 7 Z110
B3908
Receive data from 1
st
CB/TB, word 9, bit 8 Z110
B3909
Receive data from 1
st
CB/TB, word 9, bit 9 Z110
B3910
Receive data from 1
st
CB/TB, word 9, bit 10 Z110
B3911
Receive data from 1
st
CB/TB, word 9, bit 11 Z110
B3912
Receive data from 1
st
CB/TB, word 9, bit 12 Z110
B3913
Receive data from 1
st
CB/TB, word 9, bit 13 Z110
B3914
Receive data from 1
st
CB/TB, word 9, bit 14 Z110
B3915
Receive data from 1
st
CB/TB, word 9, bit 15 Z110
SCB1 with SCI
B4100
SCI, slave 1, binary input 1 [SW 1.9 and later] Z130, Z140
B4101
SCI, slave 1, binary input 2 [SW 1.9 and later] Z130, Z140
B4102
SCI, slave 1, binary input 3 [SW 1.9 and later] Z130, Z140
B4103
SCI, slave 1, binary input 4 [SW 1.9 and later] Z130, Z140
B4104
SCI, slave 1, binary input 5 [SW 1.9 and later] Z130, Z140
B4105
SCI, slave 1, binary input 6 [SW 1.9 and later] Z130, Z140
B4106
SCI, slave 1, binary input 7 [SW 1.9 and later] Z130, Z140
B4107
SCI, slave 1, binary input 8 [SW 1.9 and later] Z130, Z140
B4108
SCI, slave 1, binary input 9 [SW 1.9 and later] Z130, Z140
B4109
SCI, slave 1, binary input 10 [SW 1.9 and later] Z140
B4110
SCI, slave 1, binary input 11 [SW 1.9 and later] Z140
B4111
SCI, slave 1, binary input 12 [SW 1.9 and later] Z140
B4112
SCI, slave 1, binary input 13 [SW 1.9 and later] Z140
B4113
SCI, slave 1, binary input 14 [SW 1.9 and later] Z140
B4114
SCI, slave 1, binary input 15 [SW 1.9 and later] Z140
B4115
SCI, slave 1, binary input 16 [SW 1.9 and later] Z140
B4120
SCI, slave 1, binary input 1 inverted [SW 1.9 and later] Z130, Z140
B4121
SCI, slave 1, binary input 2 inverted [SW 1.9 and later] Z130, Z140
B4122
SCI, slave 1, binary input 3 inverted [SW 1.9 and later] Z130, Z140
B4123
SCI, slave 1, binary input 4 inverted [SW 1.9 and later] Z130, Z140
B4124
SCI, slave 1, binary input 5 inverted [SW 1.9 and later] Z130, Z140
B4125
SCI, slave 1, binary input 6 inverted [SW 1.9 and later] Z130, Z140
B4126
SCI, slave 1, binary input 7 inverted [SW 1.9 and later] Z130, Z140
B4127
SCI, slave 1, binary input 8 inverted [SW 1.9 and later] Z130, Z140
B4128
SCI, slave 1, binary input 9 inverted [SW 1.9 and later] Z130, Z140
B4129
SCI, slave 1, binary input 10 inverted [SW 1.9 and later] Z140
B4130
SCI, slave 1, binary input 11 inverted [SW 1.9 and later] Z140
B4131
SCI, slave 1, binary input 12 inverted [SW 1.9 and later] Z140
B4132
SCI, slave 1, binary input 13 inverted [SW 1.9 and later] Z140
B4133
SCI, slave 1, binary input 14 inverted [SW 1.9 and later] Z140
B4134
SCI, slave 1, binary input 15 inverted [SW 1.9 and later] Z140
B4135
SCI, slave 1, binary input 16 inverted [SW 1.9 and later] Z140
B4200
SCI, slave 2, binary input 1 [SW 1.9 and later] Z131, Z141
B4201
SCI, slave 2, binary input 2 [SW 1.9 and later] Z131, Z141
B4202
SCI, slave 2, binary input 3 [SW 1.9 and later] Z131, Z141
B4203
SCI, slave 2, binary input 4 [SW 1.9 and later] Z131, Z141
B4204
SCI, slave 2, binary input 5 [SW 1.9 and later] Z131, Z141
B4205
SCI, slave 2, binary input 6 [SW 1.9 and later] Z131, Z141
