Binector Name, description Function
diag., Sheet
B4206
SCI, slave 2, binary input 7 [SW 1.9 and later] Z131, Z141
B4207
SCI, slave 2, binary input 8 [SW 1.9 and later] Z131, Z141
B4208
SCI, slave 2, binary input 9 [SW 1.9 and later] Z131, Z141
B4209
SCI, slave 2, binary input 10 [SW 1.9 and later] Z141
B4210
SCI, slave 2, binary input 11 [SW 1.9 and later] Z141
B4211
SCI, slave 2, binary input 12 [SW 1.9 and later] Z141
B4212
SCI, slave 2, binary input 13 [SW 1.9 and later] Z141
B4213
SCI, slave 2, binary input 14 [SW 1.9 and later] Z141
B4214
SCI, slave 2, binary input 15 [SW 1.9 and later] Z141
B4215
SCI, slave 2, binary input 16 [SW 1.9 and later] Z141
B4220
SCI, slave 2, binary input 1 inverted [SW 1.9 and later] Z131, Z141
B4221
SCI, slave 2, binary input 2 inverted [SW 1.9 and later] Z131, Z141
B4222
SCI, slave 2, binary input 3 inverted [SW 1.9 and later] Z131, Z141
B4223
SCI, slave 2, binary input 4 inverted [SW 1.9 and later] Z131, Z141
B4224
SCI, slave 2, binary input 5 inverted [SW 1.9 and later] Z131, Z141
B4225
SCI, slave 2, binary input 6 inverted [SW 1.9 and later] Z131, Z141
B4226
SCI, slave 2, binary input 7 inverted [SW 1.9 and later] Z131, Z141
B4227
SCI, slave 2, binary input 8 inverted [SW 1.9 and later] Z131, Z141
B4228
SCI, slave 2, binary input 9 inverted [SW 1.9 and later] Z131, Z141
B4229
SCI, slave 2, binary input 10 inverted [SW 1.9 and later] Z141
B4230
SCI, slave 2, binary input 11 inverted [SW 1.9 and later] Z141
B4231
SCI, slave 2, binary input 12 inverted [SW 1.9 and later] Z141
B4232
SCI, slave 2, binary input 13 inverted [SW 1.9 and later] Z141
B4233
SCI, slave 2, binary input 14 inverted [SW 1.9 and later] Z141
B4234
SCI, slave 2, binary input 15 inverted [SW 1.9 and later] Z141
B4235
SCI, slave 2, binary input 16 inverted [SW 1.9 and later] Z141
Optional supplementary boards: 1st expansion board EB1 [SW 1.5 and later]
B5101
Analog input terminal 50 / 51: 1 = wire break (i
≤ 2 mA)
Z112
B5102
Analog input terminal 52 (use as digital input): 1 = input voltage is > 8V (log "1") Z112
B5103
Analog input terminal 53 (use as digital input): 1 = input voltage is > 8V (log "1") Z112
B5104
State terminal 43 (bidirectional input/output) inverted Z114
B5105
State terminal 43 (bidirectional input/output) Z114
B5106
State terminal 44 (bidirectional input/output) inverted Z114
B5107
State terminal 44 (bidirectional input/output) Z114
B5108
State terminal 45 (bidirectional Input/output) inverted Z114
B5109
State terminal 45 (bidirectional input/output) Z114
B5110
State terminal 46 (bidirectional input/output) inverted Z114
B5111
State terminal 46 (bidirectional Input/output) Z114
B5112
State terminal 40 (digital input) inverted Z114
B5113
State terminal 40 (digital input) Z114
B5114
State terminal 41 (digital input) inverted Z114
B5115
State terminal 41 (digital input) Z114
B5116
State terminal 42 (digital input) inverted Z114
B5117
State terminal 42 (digital input) Z114
Optional supplementary boards: 1st Expansion board EB2 [SW 1.5 and later]
B5121
Analog input terminal 49 / 50: 1 = wire break (i
≤ 2 mA)
Z118
B5122
State terminal 53 (digital input) inverted Z118
B5123
State terminal 53 (digital input) Z118
