05.05 Connectors and binectors
SIEMENS AG 6RX1700-0AD76 12-39
SIMOREG DC Master Operating Instructions
Binector Name, description Function
diag., Sheet
B5124
State terminal 54 (digital input) inverted Z118
B5125
State terminal 54 (digital input) Z118
Optional supplementary boards: 2
nd
expansion board EB1 [SW 1.5 and later]
B5201
Analog input terminal 50 / 51: 1 = wire break (i
≤ 2 mA)
Z115
B5202
Analog input terminal 52 (use as digital input): 1 = input voltage is > 8V (log "1") Z115
B5203
Analog input terminal 53 (use as digital input): 1 = input voltage is > 8V (log "1") Z115
B5204
State terminal 43 (bidirectional input/output) inverted Z117
B5205
State terminal 43 (bidirectional input/output) Z117
B5206
State terminal 44 (bidirectional input/output) inverted Z117
B5207
State terminal 44 (bidirectional input/output) Z117
B5208
State terminal 45 (bidirectional Input/output) inverted Z117
B5209
State terminal 45 (bidirectional input/output) Z117
B5210
State terminal 46 (bidirectional input/output) inverted Z117
B5211
State terminal 46 (bidirectional Input/output) Z117
B5212
State terminal 40 (digital input) inverted Z117
B5213
State terminal 40 (digital input) Z117
B5214
State terminal 41 (digital input) inverted Z117
B5215
State terminal 41 (digital input) Z117
B5216
State terminal 42 (digital input) inverted Z117
B5217
State terminal 42 (digital input) Z117
Optional supplementary boards: 2
nd
Expansion board EB2 [SW 1.5 and later]
B5221
Analog input terminal 49 / 50: 1 = wire break (i
≤ 2 mA)
Z119
B5222
State terminal 53 (digital input) inverted Z119
B5223
State terminal 53 (digital input) Z119
B5224
State terminal 54 (digital input) inverted Z119
B5225
State terminal 54 (digital input) Z119
Serial interface 2 (USS2 / Peer-to-peer 2 on G-SST2)
B6030
USS2 / Peer2 - Telegram monitoring timeout - maintained signal G171, G173
B6031
USS2 / Peer2 - Telegram monitoring timeout - 1s pulse G171, G173
Paralleling interface
B6040
Telegram monitoring timeout - maintained signal G195
B6041
Telegram monitoring timeout - 1s pulse G195
Serial interface 2 (USS2 / Peer-to-peer 2 on G-SST2)
B6100
USS2 / Peer2 receive data, word 1, bit 0 G171, G173
B6101
USS2 / Peer2 receive data, word 1, bit 1 G171, G173
B6102
USS2 / Peer2 receive data, word 1, bit 2 G171, G173
B6103
USS2 / Peer2 receive data, word 1, bit 3 G171, G173
B6104
USS2 / Peer2 receive data, word 1, bit 4 G171, G173
B6105
USS2 / Peer2 receive data, word 1, bit 5 G171, G173
B6106
USS2 / Peer2 receive data, word 1, bit 6 G171, G173
B6107
USS2 / Peer2 receive data, word 1, bit 7 G171, G173
B6108
USS2 / Peer2 receive data, word 1, bit 8 G171, G173
B6109
USS2 / Peer2 receive data, word 1, bit 9 G171, G173
B6110
USS2 / Peer2 receive data, word 1, bit 10 G171, G173
B6111
USS2 / Peer2 receive data, word 1, bit 11 G171, G173
