Binector Name, description Function
diag., Sheet
B6112
USS2 / Peer2 receive data, word 1, bit 12 G171, G173
B6113
USS2 / Peer2 receive data, word 1, bit 13 G171, G173
B6114
USS2 / Peer2 receive data, word 1, bit 14 G171, G173
B6115
USS2 / Peer2 receive data, word 1, bit 15 G171, G173
B6200
USS2 / Peer2 receive data, word 2, bit 0 G171, G173
B6201
USS2 / Peer2 receive data, word 2, bit 1 G171, G173
B6202
USS2 / Peer2 receive data, word 2, bit 2 G171, G173
B6203
USS2 / Peer2 receive data, word 2, bit 3 G171, G173
B6204
USS2 / Peer2 receive data, word 2, bit 4 G171, G173
B6205
USS2 / Peer2 receive data, word 2, bit 5 G171, G173
B6206
USS2 / Peer2 receive data, word 2, bit 6 G171, G173
B6207
USS2 / Peer2 receive data, word 2, bit 7 G171, G173
B6208
USS2 / Peer2 receive data, word 2, bit 8 G171, G173
B6209
USS2 / Peer2 receive data, word 2, bit 9 G171, G173
B6210
USS2 / Peer2 receive data, word 2, bit 10 G171, G173
B6211
USS2 / Peer2 receive data, word 2, bit 11 G171, G173
B6212
USS2 / Peer2 receive data, word 2, bit 12 G171, G173
B6213
USS2 / Peer2 receive data, word 2, bit 13 G171, G173
B6214
USS2 / Peer2 receive data, word 2, bit 14 G171, G173
B6215
USS2 / Peer2 receive data, word 2, bit 15 G171, G173
Paralleling interface
B6220
Word 1 from master / Word 1 from slave with address 2, bit 0 G195
B6221
Word 1 from master / Word 1 from slave with address 2, bit 1 G195
B6222
Word 1 from master / Word 1 from slave with address 2, bit 2 G195
B6223
Word 1 from master / Word 1 from slave with address 2, bit 3 G195
B6224
Word 1 from master / Word 1 from slave with address 2, bit 4 G195
B6225
Word 1 from master / Word 1 from slave with address 2, bit 5 G195
B6226
Word 1 from master / Word 1 from slave with address 2, bit 6 G195
B6227
Word 1 from master / Word 1 from slave with address 2, bit 7 G195
B6228
Word 1 from master / Word 1 from slave with address 2, bit 8 G195
B6229
Word 1 from master / Word 1 from slave with address 2, bit 9 G195
B6230
Word 1 from master / Word 1 from slave with address 2, bit 10 G195
B6231
Word 1 from master / Word 1 from slave with address 2, bit 11 G195
B6232
Word 1 from master / Word 1 from slave with address 2, bit 12 G195
B6233
Word 1 from master / Word 1 from slave with address 2, bit 13 G195
B6234
Word 1 from master / Word 1 from slave with address 2, bit 14 G195
B6235
Word 1 from master / Word 1 from slave with address 2, bit 15 G195
Serial interface 2 (USS2 / Peer-to-peer 2 on G-SST2)
B6300
USS2 / Peer2 receive data, word 3, bit 0 G171, G173
B6301
USS2 / Peer2 receive data, word 3, bit 1 G171, G173
B6302
USS2 / Peer2 receive data, word 3, bit 2 G171, G173
B6303
USS2 / Peer2 receive data, word 3, bit 3 G171, G173
B6304
USS2 / Peer2 receive data, word 3, bit 4 G171, G173
B6305
USS2 / Peer2 receive data, word 3, bit 5 G171, G173
B6306
USS2 / Peer2 receive data, word 3, bit 6 G171, G173
B6307
USS2 / Peer2 receive data, word 3, bit 7 G171, G173
B6308
USS2 / Peer2 receive data, word 3, bit 8 G171, G173
B6309
USS2 / Peer2 receive data, word 3, bit 9 G171, G173
