05.05 Connectors and binectors
SIEMENS AG 6RX1700-0AD76 12-41
SIMOREG DC Master Operating Instructions
Binector Name, description Function
diag., Sheet
B6310
USS2 / Peer2 receive data, word 3, bit 10 G171, G173
B6311
USS2 / Peer2 receive data, word 3, bit 11 G171, G173
B6312
USS2 / Peer2 receive data, word 3, bit 12 G171, G173
B6313
USS2 / Peer2 receive data, word 3, bit 13 G171, G173
B6314
USS2 / Peer2 receive data, word 3, bit 14 G171, G173
B6315
USS2 / Peer2 receive data, word 3, bit 15 G171, G173
Paralleling interface
B6320
Word 1 from slave with address 3, bit 0 G195
B6321
Word 1 from slave with address 3, bit 1 G195
B6322
Word 1 from slave with address 3, bit 2 G195
B6323
Word 1 from slave with address 3, bit 3 G195
B6324
Word 1 from slave with address 3, bit 4 G195
B6325
Word 1 from slave with address 3, bit 5 G195
B6326
Word 1 from slave with address 3, bit 6 G195
B6327
Word 1 from slave with address 3, bit 7 G195
B6328
Word 1 from slave with address 3, bit 8 G195
B6329
Word 1 from slave with address 3, bit 9 G195
B6330
Word 1 from slave with address 3, bit 10 G195
B6331
Word 1 from slave with address 3, bit 11 G195
B6332
Word 1 from slave with address 3, bit 12 G195
B6333
Word 1 from slave with address 3, bit 13 G195
B6334
Word 1 from slave with address 3, bit 14 G195
B6335
Word 1 from slave with address 3, bit 15 G195
Serial interface 2 (USS2 / Peer-to-peer 2 on G-SST2)
B6400
USS2 / Peer2 receive data, word 4, bit 0 G171, G173
B6401
USS2 / Peer2 receive data, word 4, bit 1 G171, G173
B6402
USS2 / Peer2 receive data, word 4, bit 2 G171, G173
B6403
USS2 / Peer2 receive data, word 4, bit 3 G171, G173
B6404
USS2 / Peer2 receive data, word 4, bit 4 G171, G173
B6405
USS2 / Peer2 receive data, word 4, bit 5 G171, G173
B6406
USS2 / Peer2 receive data, word 4, bit 6 G171, G173
B6407
USS2 / Peer2 receive data, word 4, bit 7 G171, G173
B6408
USS2 / Peer2 receive data, word 4, bit 8 G171, G173
B6409
USS2 / Peer2 receive data, word 4, bit 9 G171, G173
B6410
USS2 / Peer2 receive data, word 4, bit 10 G171, G173
B6411
USS2 / Peer2 receive data, word 4, bit 11 G171, G173
B6412
USS2 / Peer2 receive data, word 4, bit 12 G171, G173
B6413
USS2 / Peer2 receive data, word 4, bit 13 G171, G173
B6414
USS2 / Peer2 receive data, word 4, bit 14 G171, G173
B6415
USS2 / Peer2 receive data, word 4, bit 15 G171, G173
Paralleling interface
B6420
Word 1 from slave with address 4, bit 0 G195
B6421
Word 1 from slave with address 4, bit 1 G195
B6422
Word 1 from slave with address 4, bit 2 G195
B6423
Word 1 from slave with address 4, bit 3 G195
B6424
Word 1 from slave with address 4, bit 4 G195
B6425
Word 1 from slave with address 4, bit 5 G195
