SIMOREG DC Master Operating Instructions
Binector Name, description Function
diag., Sheet
B6426
Word 1 from slave with address 4, bit 6 G195
B6427
Word 1 from slave with address 4, bit 7 G195
B6428
Word 1 from slave with address 4, bit 8 G195
B6429
Word 1 from slave with address 4, bit 9 G195
B6430
Word 1 from slave with address 4, bit 10 G195
B6431
Word 1 from slave with address 4, bit 11 G195
B6432
Word 1 from slave with address 4, bit 12 G195
B6433
Word 1 from slave with address 4, bit 13 G195
B6434
Word 1 from slave with address 4, bit 14 G195
B6435
Word 1 from slave with address 4, bit 15 G195
Serial interface 2 (USS2 / Peer-to-peer 2 on G-SST2)
B6500
USS2 / Peer2 receive data, word 5, bit 0 G171, G173
B6501
USS2 / Peer2 receive data, word 5, bit 1 G171, G173
B6502
USS2 / Peer2 receive data, word 5, bit 2 G171, G173
B6503
USS2 / Peer2 receive data, word 5, bit 3 G171, G173
B6504
USS2 / Peer2 receive data, word 5, bit 4 G171, G173
B6505
USS2 / Peer2 receive data, word 5, bit 5 G171, G173
B6506
USS2 / Peer2 receive data, word 5, bit 6 G171, G173
B6507
USS2 / Peer2 receive data, word 5, bit 7 G171, G173
B6508
USS2 / Peer2 receive data, word 5, bit 8 G171, G173
B6509
USS2 / Peer2 receive data, word 5, bit 9 G171, G173
B6510
USS2 / Peer2 receive data, word 5, bit 10 G171, G173
B6511
USS2 / Peer2 receive data, word 5, bit 11 G171, G173
B6512
USS2 / Peer2 receive data, word 5, bit 12 G171, G173
B6513
USS2 / Peer2 receive data, word 5, bit 13 G171, G173
B6514
USS2 / Peer2 receive data, word 5, bit 14 G171, G173
B6515
USS2 / Peer2 receive data, word 5, bit 15 G171, G173
Paralleling interface
B6520
Word 1 from slave with address 5, bit 0 G195
B6521
Word 1 from slave with address 5, bit 1 G195
B6522
Word 1 from slave with address 5, bit 2 G195
B6523
Word 1 from slave with address 5, bit 3 G195
B6524
Word 1 from slave with address 5, bit 4 G195
B6525
Word 1 from slave with address 5, bit 5 G195
B6526
Word 1 from slave with address 5, bit 6 G195
B6527
Word 1 from slave with address 5, bit 7 G195
B6528
Word 1 from slave with address 5, bit 8 G195
B6529
Word 1 from slave with address 5, bit 9 G195
B6530
Word 1 from slave with address 5, bit 10 G195
B6531
Word 1 from slave with address 5, bit 11 G195
B6532
Word 1 from slave with address 5, bit 12 G195
B6533
Word 1 from slave with address 5, bit 13 G195
B6534
Word 1 from slave with address 5, bit 14 G195
B6535
Word 1 from slave with address 5, bit 15 G195
Serial interface 2 (USS2 / Peer-to-peer 2 on G-SST2)
B6600
USS2 receive data, word 6, bit 0 G171
B6601
USS2 receive data, word 6, bit 1 G171
