05.05 Connectors and binectors
SIEMENS AG 6RX1700-0AD76 12-43
SIMOREG DC Master Operating Instructions
Binector Name, description Function
diag., Sheet
B6602
USS2 receive data, word 6, bit 2 G171
B6603
USS2 receive data, word 6, bit 3 G171
B6604
USS2 receive data, word 6, bit 4 G171
B6605
USS2 receive data, word 6, bit 5 G171
B6606
USS2 receive data, word 6, bit 6 G171
B6607
USS2 receive data, word 6, bit 7 G171
B6608
USS2 receive data, word 6, bit 8 G171
B6609
USS2 receive data, word 6, bit 9 G171
B6610
USS2 receive data, word 6, bit 10 G171
B6611
USS2 receive data, word 6, bit 11 G171
B6612
USS2 receive data, word 6, bit 12 G171
B6613
USS2 receive data, word 6, bit 13 G171
B6614
USS2 receive data, word 6, bit 14 G171
B6615
USS2 receive data, word 6, bit 15 G171
Paralleling interface
B6620
Word 1 from slave with address 6, bit 0 G195
B6621
Word 1 from slave with address 6, bit 1 G195
B6622
Word 1 from slave with address 6, bit 2 G195
B6623
Word 1 from slave with address 6, bit 3 G195
B6624
Word 1 from slave with address 6, bit 4 G195
B6625
Word 1 from slave with address 6, bit 5 G195
B6626
Word 1 from slave with address 6, bit 6 G195
B6627
Word 1 from slave with address 6, bit 7 G195
B6628
Word 1 from slave with address 6, bit 8 G195
B6629
Word 1 from slave with address 6, bit 9 G195
B6630
Word 1 from slave with address 6, bit 10 G195
B6631
Word 1 from slave with address 6, bit 11 G195
B6632
Word 1 from slave with address 6, bit 12 G195
B6633
Word 1 from slave with address 6, bit 13 G195
B6634
Word 1 from slave with address 6, bit 14 G195
B6635
Word 1 from slave with address 6, bit 15 G195
Serial interface 2 (USS2 / Peer-to-peer 2 on G-SST2)
B6700
USS2 receive data, word 7, bit 0 G171
B6701
USS2 receive data, word 7, bit 1 G171
B6702
USS2 receive data, word 7, bit 2 G171
B6703
USS2 receive data, word 7, bit 3 G171
B6704
USS2 receive data, word 7, bit 4 G171
B6705
USS2 receive data, word 7, bit 5 G171
B6706
USS2 receive data, word 7, bit 6 G171
B6707
USS2 receive data, word 7, bit 7 G171
B6708
USS2 receive data, word 7, bit 8 G171
B6709
USS2 receive data, word 7, bit 9 G171
B6710
USS2 receive data, word 7, bit 10 G171
B6711
USS2 receive data, word 7, bit 11 G171
B6712
USS2 receive data, word 7, bit 12 G171
B6713
USS2 receive data, word 7, bit 13 G171
B6714
USS2 receive data, word 7, bit 14 G171
B6715
USS2 receive data, word 7, bit 15 G171
