Connectors and binectors 05.05
12-44 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
Binector Name, description Function
diag., Sheet
B6800
USS2 receive data, word 8, bit 0 G171
B6801
USS2 receive data, word 8, bit 1 G171
B6802
USS2 receive data, word 8, bit 2 G171
B6803
USS2 receive data, word 8, bit 3 G171
B6804
USS2 receive data, word 8, bit 4 G171
B6805
USS2 receive data, word 8, bit 5 G171
B6806
USS2 receive data, word 8, bit 6 G171
B6807
USS2 receive data, word 8, bit 7 G171
B6808
USS2 receive data, word 8, bit 8 G171
B6809
USS2 receive data, word 8, bit 9 G171
B6810
USS2 receive data, word 8, bit 10 G171
B6811
USS2 receive data, word 8, bit 11 G171
B6812
USS2 receive data, word 8, bit 12 G171
B6813
USS2 receive data, word 8, bit 13 G171
B6814
USS2 receive data, word 8, bit 14 G171
B6815
USS2 receive data, word 8, bit 15 G171
B6900
USS2 receive data, word 9, bit 0 G171
B6901
USS2 receive data, word 9, bit 1 G171
B6902
USS2 receive data, word 9, bit 2 G171
B6903
USS2 receive data, word 9, bit 3 G171
B6904
USS2 receive data, word 9, bit 4 G171
B6905
USS2 receive data, word 9, bit 5 G171
B6906
USS2 receive data, word 9, bit 6 G171
B6907
USS2 receive data, word 9, bit 7 G171
B6908
USS2 receive data, word 9, bit 8 G171
B6909
USS2 receive data, word 9, bit 9 G171
B6910
USS2 receive data, word 9, bit 10 G171
B6911
USS2 receive data, word 9, bit 11 G171
B6912
USS2 receive data, word 9, bit 12 G171
B6913
USS2 receive data, word 9, bit 13 G171
B6914
USS2 receive data, word 9, bit 14 G171
B6915
USS2 receive data, word 9, bit 15 G171
Optional supplementary boards: SBP pulse encoder evaluation [SW 1.5 and later]
B7000
State terminal 74 / 75 (check track) Z120
B7001
State terminal 65 (coarse pulse 1) Z120
B7002
State terminal 66 (coarse pulse 2) Z120
B7003
State terminal 67 (fine pulse 2) Z120
Optional supplementary boards: SIMOLINK board [SW 1.5 and later]
B7030
1 = Telegram failure Z121
B7040
1 = Time out Z121
B7050
1 = Alarm start-up Z121
B7100
Receive data from the SIMOLINK board, word 1 bit 0 Z122
B7101
Receive data from the SIMOLINK board, word 1 bit 1 Z122
B7102
Receive data from the SIMOLINK board, word 1 bit 2 Z122
B7103
Receive data from the SIMOLINK board, word 1 bit 3 Z122
B7104
Receive data from the SIMOLINK board, word 1 bit 4 Z122
B7105
Receive data from the SIMOLINK board, word 1 bit 5 Z122
B7106
Receive data from the SIMOLINK board, word 1 bit 6 Z122
