Siemens 6RA7086-6KS22

Connectors and binectors 05.05
12-50 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
Binector Name, description Function
diag., Sheet
B8710
Receive data from 2
nd
CB, word 7, bit 10 Z111
B8711
Receive data from 2
nd
CB, word 7, bit 11 Z111
B8712
Receive data from 2
nd
CB, word 7, bit 12 Z111
B8713
Receive data from 2
nd
CB, word 7, bit 13 Z111
B8714
Receive data from 2
nd
CB, word 7, bit 14 Z111
B8715
Receive data from 2
nd
CB, word 7, bit 15 Z111
B8800
Receive data from 2
nd
CB, word 8, bit 0 Z111
B8801
Receive data from 2
nd
CB, word 8, bit 1 Z111
B8802
Receive data from 2
nd
CB, word 8, bit 2 Z111
B8803
Receive data from 2
nd
CB, word 8, bit 3 Z111
B8804
Receive data from 2
nd
CB, word 8, bit 4 Z111
B8805
Receive data from 2
nd
CB, word 8, bit 5 Z111
B8806
Receive data from 2
nd
CB, word 8, bit 6 Z111
B8807
Receive data from 2
nd
CB, word 8, bit 7 Z111
B8808
Receive data from 2
nd
CB, word 8, bit 8 Z111
B8809
Receive data from 2
nd
CB, word 8, bit 9 Z111
B8810
Receive data from 2
nd
CB, word 8, bit 10 Z111
B8811
Receive data from 2
nd
CB, word 8, bit 11 Z111
B8812
Receive data from 2
nd
CB, word 8, bit 12 Z111
B8813
Receive data from 2
nd
CB, word 8, bit 13 Z111
B8814
Receive data from 2
nd
CB, word 8, bit 14 Z111
B8815
Receive data from 2
nd
CB, word 8, bit 15 Z111
B8900
Receive data from 2
nd
CB, word 9, bit 0 Z111
B8901
Receive data from 2
nd
CB, word 9, bit 1 Z111
B8902
Receive data from 2
nd
CB, word 9, bit 2 Z111
B8903
Receive data from 2
nd
CB, word 9, bit 3 Z111
B8904
Receive data from 2
nd
CB, word 9, bit 4 Z111
B8905
Receive data from 2
nd
CB, word 9, bit 5 Z111
B8906
Receive data from 2
nd
CB, word 9, bit 6 Z111
B8907
Receive data from 2
nd
CB, word 9, bit 7 Z111
B8908
Receive data from 2
nd
CB, word 9, bit 8 Z111
B8909
Receive data from 2
nd
CB, word 9, bit 9 Z111
B8910
Receive data from 2
nd
CB, word 9, bit 10 Z111
B8911
Receive data from 2
nd
CB, word 9, bit 11 Z111
B8912
Receive data from 2
nd
CB, word 9, bit 12 Z111
B8913
Receive data from 2
nd
CB, word 9, bit 13 Z111
B8914
Receive data from 2
nd
CB, word 9, bit 14 Z111
B8915
Receive data from 2
nd
CB, word 9, bit 15 Z111
Serial interface 3 (USS3 / Peer-to-peer 3 on G-SST3)
B9030
USS3 / Peer3 - Telegram monitoring timeout - maintained signal G172, G174
B9031
USS3 / Peer3 - Telegram monitoring timeout - 1s pulse G172, G174
Technology software S00: Voltage monitor for electronics power supply
B9050
Power ON (100ms pulse on connection of voltage) B110
B9051
Power OFF (10ms pulse on disconnection of voltage) B110
Technology software S00: Connector/binector converters
B9052
Connector/binector converter 1, bit 0 FB 10 B120
B9053
Connector/binector converter 1, bit 1 FB 10 B120
