Siemens 6RA7086-6KS22

05.05 Connectors and binectors
SIEMENS AG 6RX1700-0AD76 12-51
SIMOREG DC Master Operating Instructions
Binector Name, description Function
diag., Sheet
B9054
Connector/binector converter 1, bit 2 FB 10 B120
B9055
Connector/binector converter 1, bit 3 FB 10 B120
B9056
Connector/binector converter 1, bit 4 FB 10 B120
B9057
Connector/binector converter 1, bit 5 FB 10 B120
B9058
Connector/binector converter 1, bit 6 FB 10 B120
B9059
Connector/binector converter 1, bit 7 FB 10 B120
B9060
Connector/binector converter 1, bit 8 FB 10 B120
B9061
Connector/binector converter 1, bit 9 FB 10 B120
B9062
Connector/binector converter 1, bit 10 FB 10 B120
B9063
Connector/binector converter 1, bit 11 FB 10 B120
B9064
Connector/binector converter 1, bit 12 FB 10 B120
B9065
Connector/binector converter 1, bit 13 FB 10 B120
B9066
Connector/binector converter 1, bit 14 FB 10 B120
B9067
Connector/binector converter 1, bit 15 FB 10 B120
B9068
Connector/binector converter 2, bit 0 FB 11 B120
B9069
Connector/binector converter 2, bit 1 FB 11 B120
B9070
Connector/binector converter 2, bit 2 FB 11 B120
B9071
Connector/binector converter 2, bit 3 FB 11 B120
B9072
Connector/binector converter 2, bit 4 FB 11 B120
B9073
Connector/binector converter 2, bit 5 FB 11 B120
B9074
Connector/binector converter 2, bit 6 FB 11 B120
B9075
Connector/binector converter 2, bit 7 FB 11 B120
B9076
Connector/binector converter 2, bit 8 FB 11 B120
B9077
Connector/binector converter 2, bit 9 FB 11 B120
B9078
Connector/binector converter 2, bit 10 FB 11 B120
B9079
Connector/binector converter 2, bit 11 FB 11 B120
B9080
Connector/binector converter 2, bit 12 FB 11 B120
B9081
Connector/binector converter 2, bit 13 FB 11 B120
B9082
Connector/binector converter 2, bit 14 FB 11 B120
B9083
Connector/binector converter 2, bit 15 FB 11 B120
B9084
Connector/binector converter 3, bit 0 FB 12 B120
B9085
Connector/binector converter 3, bit 1 FB 12 B120
B9086
Connector/binector converter 3, bit 2 FB 12 B120
B9087
Connector/binector converter 3, bit 3 FB 12 B120
B9088
Connector/binector converter 3, bit 4 FB 12 B120
B9089
Connector/binector converter 3, bit 5 FB 12 B120
B9090
Connector/binector converter 3, bit 6 FB 12 B120
B9091
Connector/binector converter 3, bit 7 FB 12 B120
B9092
Connector/binector converter 3, bit 8 FB 12 B120
B9093
Connector/binector converter 3, bit 9 FB 12 B120
B9094
Connector/binector converter 3, bit 10 FB 12 B120
B9095
Connector/binector converter 3, bit 11 FB 12 B120
B9096
Connector/binector converter 3, bit 12 FB 12 B120
B9097
Connector/binector converter 3, bit 13 FB 12 B120
B9098
Connector/binector converter 3, bit 14 FB 12 B120
B9099
Connector/binector converter 3, bit 15 FB 12 B120
Serial interface 3 (USS3 / Peer-to-peer 3 on G-SST3)
B9100
USS3 / Peer3 receive data, word 1, bit 0 G172, G174
B9101
USS3 / Peer3 receive data, word 1, bit 1 G172, G174
