Siemens 6RA7086-6KS22

Connectors and binectors 05.05
12-52 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
Binector Name, description Function
diag., Sheet
B9102
USS3 / Peer3 receive data, word 1, bit 2 G172, G174
B9103
USS3 / Peer3 receive data, word 1, bit 3 G172, G174
B9104
USS3 / Peer3 receive data, word 1, bit 4 G172, G174
B9105
USS3 / Peer3 receive data, word 1, bit 5 G172, G174
B9106
USS3 / Peer3 receive data, word 1, bit 6 G172, G174
B9107
USS3 / Peer3 receive data, word 1, bit 7 G172, G174
B9108
USS3 / Peer3 receive data, word 1, bit 8 G172, G174
B9109
USS3 / Peer3 receive data, word 1, bit 9 G172, G174
B9110
USS3 / Peer3 receive data, word 1, bit 10 G172, G174
B9111
USS3 / Peer3 receive data, word 1, bit 11 G172, G174
B9112
USS3 / Peer3 receive data, word 1, bit 12 G172, G174
B9113
USS3 / Peer3 receive data, word 1, bit 13 G172, G174
B9114
USS3 / Peer3 receive data, word 1, bit 14 G172, G174
B9115
USS3 / Peer3 receive data, word 1, bit 15 G172, G174
Technology software S00: Limiters
B9150
Limiter 1: Positive limitation has responded FB 65 B135
B9151
Limiter 1: Negative limitation has responded FB 65 B135
B9152
Limiter 2: Positive limitation has responded FB 66 B135
B9153
Limiter 2: Negative limitation has responded FB 66 B135
B9154
Limiter 3: Positive limitation has responded FB 67 B135
B9155
Limiter 3: Negative limitation has responded FB 67 B135
B9156
Limiter 4: Positive limitation has responded [SW 2.0 and later] FB 212 B134
B9157
Limiter 4: Negative limitation has responded [SW 2.0 and later] FB 212 B134
B9158
Limiter 5: Positive limitation has responded [SW 2.0 and later] FB 213 B134
B9159
Limiter 5: Negative limitation has responded [SW 2.0 and later] FB 213 B134
Technology software S00: Limit-value monitor with filter
B9160
Limit-value monitor with filter 1: |A| < B has responded FB 70 B136
B9161
Limit-value monitor with filter 1: A < B has responded FB 70 B136
B9162
Limit-value monitor with filter 1: A = B has responded FB 70 B136
B9163
Limit-value monitor with filter 2: |A| < B has responded FB 71 B136
B9164
Limit-value monitor with filter 2: A < B has responded FB 71 B136
B9165
Limit-value monitor with filter 2: A = B has responded FB 71 B136
B9166
Limit-value monitor with filter 3: |A| < B has responded FB 72 B136
B9167
Limit-value monitor with filter 3: A < B has responded FB 72 B136
B9168
Limit-value monitor with filter 3: A = B has responded FB 72 B136
Technology software S00: Limit-value monitor without filter
B9169
Limit-value monitor without filter 1: |A| < B has responded FB 73 B137
B9170
Limit-value monitor without filter 1: A < B has responded FB 73 B137
B9171
Limit-value monitor without filter 1: A = B has responded FB 73 B137
B9172
Limit-value monitor without filter 2: |A| < B has responded FB 74 B137
B9173
Limit-value monitor without filter 2: A < B has responded FB 74 B137
B9174
Limit-value monitor without filter 2: A = B has responded FB 74 B137
B9175
Limit-value monitor without filter 3: |A| < B has responded FB 75 B137
B9176
Limit-value monitor without filter 3: A < B has responded FB 75 B137
B9177
Limit-value monitor without filter 3: A = B has responded FB 75 B137
B9178
Limit-value monitor without filter 4: |A| < B has responded FB 76 B137
B9179
Limit-value monitor without filter 4: A < B has responded FB 76 B137
