05.05 Connectors and binectors
SIEMENS AG 6RX1700-0AD76 12-53
SIMOREG DC Master Operating Instructions
Binector Name, description Function
diag., Sheet
B9180
Limit-value monitor without filter 4: A = B has responded FB 76 B137
B9181
Limit-value monitor without filter 5: |A| < B has responded FB 77 B138
B9182
Limit-value monitor without filter 5: A < B has responded FB 77 B138
B9183
Limit-value monitor without filter 5: A = B has responded FB 77 B138
B9184
Limit-value monitor without filter 6: |A| < B has responded FB 78 B138
B9185
Limit-value monitor without filter 6: A < B has responded FB 78 B138
B9186
Limit-value monitor without filter 6: A = B has responded FB 78 B138
B9187
Limit-value monitor without filter 7: |A| < B has responded FB 79 B138
B9188
Limit-value monitor without filter 7: A < B has responded FB 79 B138
B9189
Limit-value monitor without filter 7: A = B has responded FB 79 B138
Technology software S00: Simple ramp-function generator
B9190
Ramp-function generator output = ramp-function generator input (y = x) FB 113 B165
B9191
0 = ramp-function generator initial run FB 113 B165
Technology software S00: EXCLUSIVE OR elements with 2 inputs each
B9195
Output of EXCLUSIVE OR element 1 FB 170 B206
B9196
Output of EXCLUSIVE OR element 2 FB 171 B206
B9197
Output of EXCLUSIVE OR element 3 FB 172 B206
B9198
Output of EXCLUSIVE OR element 4 FB 173 B206
Serial interface 3 (USS3 / Peer-to-peer 3 on G-SST3)
B9200
USS3 / Peer3 receive data, word 2, bit 0 G172, G174
B9201
USS3 / Peer3 receive data, word 2, bit 1 G172, G174
B9202
USS3 / Peer3 receive data, word 2, bit 2 G172, G174
B9203
USS3 / Peer3 receive data, word 2, bit 3 G172, G174
B9204
USS3 / Peer3 receive data, word 2, bit 4 G172, G174
B9205
USS3 / Peer3 receive data, word 2, bit 5 G172, G174
B9206
USS3 / Peer3 receive data, word 2, bit 6 G172, G174
B9207
USS3 / Peer3 receive data, word 2, bit 7 G172, G174
B9208
USS3 / Peer3 receive data, word 2, bit 8 G172, G174
B9209
USS3 / Peer3 receive data, word 2, bit 9 G172, G174
B9210
USS3 / Peer3 receive data, word 2, bit 10 G172, G174
B9211
USS3 / Peer3 receive data, word 2, bit 11 G172, G174
B9212
USS3 / Peer3 receive data, word 2, bit 12 G172, G174
B9213
USS3 / Peer3 receive data, word 2, bit 13 G172, G174
B9214
USS3 / Peer3 receive data, word 2, bit 14 G172, G174
B9215
USS3 / Peer3 receive data, word 2, bit 15 G172, G174
Technology software S00: Decoders / demultiplexers, binary to 1 of 8
B9250
Decoder / demultiplexer 1: Q0 FB 118 B200
B9251
Decoder / demultiplexer 1: Q1 FB 118 B200
B9252
Decoder / demultiplexer 1: Q2 FB 118 B200
B9253
Decoder / demultiplexer 1: Q3 FB 118 B200
B9254
Decoder / demultiplexer 1: Q4 FB 118 B200
B9255
Decoder / demultiplexer 1: Q5 FB 118 B200
B9256
Decoder / demultiplexer 1: Q6 FB 118 B200
B9257
Decoder / demultiplexer 1: Q7 FB 118 B200
B9260
Decoder / demultiplexer 1: /Q0 FB 118 B200
B9261
Decoder / demultiplexer 1: /Q1 FB 118 B200
