SIMOREG DC Master Operating Instructions
Binector Name, description Function
diag., Sheet
B9262
Decoder / demultiplexer 1: /Q2 FB 118 B200
B9263
Decoder / demultiplexer 1: /Q3 FB 118 B200
B9264
Decoder / demultiplexer 1: /Q4 FB 118 B200
B9265
Decoder / demultiplexer 1: /Q5 FB 118 B200
B9266
Decoder / demultiplexer 1: /Q6 FB 118 B200
B9267
Decoder / demultiplexer 1: /Q7 FB 118 B200
B9270
Decoder / demultiplexer 2: Q0 FB 119 B200
B9271
Decoder / demultiplexer 2: Q1 FB 119 B200
B9272
Decoder / demultiplexer 2: Q2 FB 119 B200
B9273
Decoder / demultiplexer 2: Q3 FB 119 B200
B9274
Decoder / demultiplexer 2: Q4 FB 119 B200
B9275
Decoder / demultiplexer 2: Q5 FB 119 B200
B9276
Decoder / demultiplexer 2: Q6 FB 119 B200
B9277
Decoder / demultiplexer 2: Q7 FB 119 B200
B9280
Decoder / demultiplexer 2: /Q0 FB 119 B200
B9281
Decoder / demultiplexer 2: /Q1 FB 119 B200
B9282
Decoder / demultiplexer 2: /Q2 FB 119 B200
B9283
Decoder / demultiplexer 2: /Q3 FB 119 B200
B9284
Decoder / demultiplexer 2: /Q4 FB 119 B200
B9285
Decoder / demultiplexer 2: /Q5 FB 119 B200
B9286
Decoder / demultiplexer 2: /Q6 FB 119 B200
B9287
Decoder / demultiplexer 2: /Q7 FB 119 B200
S00 technology software: Software counter
B9290
Output overflow software counter [SW 1.9 and later] FB 89 B196
B9291
Output underflow software counter [SW 1.9 and later] FB 89 B196
Technology software S00: Limiters
B9295
Limiter 6: Positive limitation has responded [SW 2.0 and later] FB 214 B134
B9296
Limiter 6: Negative limitation has responded [SW 2.0 and later] FB 214 B134
Serial interface 3 (USS3 / Peer-to-peer 3 on G-SST3)
B9300
USS3 / Peer3 receive data, word 3, bit 0 G172, G174
B9301
USS3 / Peer3 receive data, word 3, bit 1 G172, G174
B9302
USS3 / Peer3 receive data, word 3, bit 2 G172, G174
B9303
USS3 / Peer3 receive data, word 3, bit 3 G172, G174
B9304
USS3 / Peer3 receive data, word 3, bit 4 G172, G174
B9305
USS3 / Peer3 receive data, word 3, bit 5 G172, G174
B9306
USS3 / Peer3 receive data, word 3, bit 6 G172, G174
B9307
USS3 / Peer3 receive data, word 3, bit 7 G172, G174
B9308
USS3 / Peer3 receive data, word 3, bit 8 G172, G174
B9309
USS3 / Peer3 receive data, word 3, bit 9 G172, G174
B9310
USS3 / Peer3 receive data, word 3, bit 10 G172, G174
B9311
USS3 / Peer3 receive data, word 3, bit 11 G172, G174
B9312
USS3 / Peer3 receive data, word 3, bit 12 G172, G174
B9313
USS3 / Peer3 receive data, word 3, bit 13 G172, G174
B9314
USS3 / Peer3 receive data, word 3, bit 14 G172, G174
B9315
USS3 / Peer3 receive data, word 3, bit 15 G172, G174
