Binector Name, description Function
diag., Sheet
B9399
Output of OR element 20 FB 169 B206
Serial interface 3 (USS3 / Peer-to-peer 3 on G-SST3)
B9400
USS3 / Peer3 receive data, word 4, bit 0 G172, G174
B9401
USS3 / Peer3 receive data, word 4, bit 1 G172, G174
B9402
USS3 / Peer3 receive data, word 4, bit 2 G172, G174
B9403
USS3 / Peer3 receive data, word 4, bit 3 G172, G174
B9404
USS3 / Peer3 receive data, word 4, bit 4 G172, G174
B9405
USS3 / Peer3 receive data, word 4, bit 5 G172, G174
B9406
USS3 / Peer3 receive data, word 4, bit 6 G172, G174
B9407
USS3 / Peer3 receive data, word 4, bit 7 G172, G174
B9408
USS3 / Peer3 receive data, word 4, bit 8 G172, G174
B9409
USS3 / Peer3 receive data, word 4, bit 9 G172, G174
B9410
USS3 / Peer3 receive data, word 4, bit 10 G172, G174
B9411
USS3 / Peer3 receive data, word 4, bit 11 G172, G174
B9412
USS3 / Peer3 receive data, word 4, bit 12 G172, G174
B9413
USS3 / Peer3 receive data, word 4, bit 13 G172, G174
B9414
USS3 / Peer3 receive data, word 4, bit 14 G172, G174
B9415
USS3 / Peer3 receive data, word 4, bit 15 G172, G174
Technology software S00: Inverters
B9450
Output of inverter 1 FB 180 B207
B9451
Output of inverter 2 FB 181 B207
B9452
Output of inverter 3 FB 182 B207
B9453
Output of inverter 4 FB 183 B207
B9454
Output of inverter 5 FB 184 B207
B9455
Output of inverter 6 FB 185 B207
B9456
Output of inverter 7 FB 186 B207
B9457
Output of inverter 8 FB 187 B207
B9458
Output of inverter 9 FB 188 B207
B9459
Output of inverter 10 FB 189 B207
B9460
Output of inverter 11 FB 190 B207
B9461
Output of inverter 12 FB 191 B207
B9462
Output of inverter 13 FB 192 B207
B9463
Output of inverter 14 FB 193 B207
B9464
Output of inverter 15 FB 194 B207
B9465
Output of inverter 16 FB 195 B207
Technology software S00: NAND elements with 3 inputs each
B9470
Output of NAND element 1 FB 200 B207
B9471
Output of NAND element 2 FB 201 B207
B9472
Output of NAND element 3 FB 202 B207
B9473
Output of NAND element 4 FB 203 B207
B9474
Output of NAND element 5 FB 204 B207
B9475
Output of NAND element 6 FB 205 B207
B9476
Output of NAND element 7 FB 206 B207
B9477
Output of NAND element 8 FB 207 B207
B9478
Output of NAND element 9 FB 208 B207
B9479
Output of NAND element 10 FB 209 B207
B9480
Output of NAND element 11 FB 210 B207
