05.05 Connectors and binectors
SIEMENS AG 6RX1700-0AD76 12-57
SIMOREG DC Master Operating Instructions
Binector Name, description Function
diag., Sheet
B9481
Output of NAND element 12 FB 211 B207
Technology software S00: Binary signal selector switches
B9482
Output of binary signal selector switch 1 FB 250 B216
B9483
Output of binary signal selector switch 2 FB 251 B216
B9484
Output of binary signal selector switch 3 FB 252 B216
B9485
Output of binary signal selector switch 4 FB 253 B216
B9486
Output of binary signal selector switch 5 FB 254 B216
Technology software S00: D flipflops
B9490
D flipflop 1: Output Q FB 230 B211
B9491
D flipflop 1: Output /Q FB 230 B211
B9492
D flipflop 2: Output Q FB 231 B211
B9493
D flipflop 2: Output /Q FB 231 B211
B9494
D flipflop 3: Output Q FB 232 B211
B9495
D flipflop 3: Output /Q FB 232 B211
B9496
D flipflop 4: Output Q FB 233 B211
B9497
D flipflop 4: Output /Q FB 233 B211
Technology software S00: Technology controller
B9499
Ramp-function generator output = ramp-function generator input (y = x) FB 113 B170
Serial interface 3 (USS3 / Peer-to-peer 3 on G-SST3)
B9500
USS3 / Peer3 receive data, word 5, bit 0 G172, G174
B9501
USS3 / Peer3 receive data, word 5, bit 1 G172, G174
B9502
USS3 / Peer3 receive data, word 5, bit 2 G172, G174
B9503
USS3 / Peer3 receive data, word 5, bit 3 G172, G174
B9504
USS3 / Peer3 receive data, word 5, bit 4 G172, G174
B9505
USS3 / Peer3 receive data, word 5, bit 5 G172, G174
B9506
USS3 / Peer3 receive data, word 5, bit 6 G172, G174
B9507
USS3 / Peer3 receive data, word 5, bit 7 G172, G174
B9508
USS3 / Peer3 receive data, word 5, bit 8 G172, G174
B9509
USS3 / Peer3 receive data, word 5, bit 9 G172, G174
B9510
USS3 / Peer3 receive data, word 5, bit 10 G172, G174
B9511
USS3 / Peer3 receive data, word 5, bit 11 G172, G174
B9512
USS3 / Peer3 receive data, word 5, bit 12 G172, G174
B9513
USS3 / Peer3 receive data, word 5, bit 13 G172, G174
B9514
USS3 / Peer3 receive data, word 5, bit 14 G172, G174
B9515
USS3 / Peer3 receive data, word 5, bit 15 G172, G174
Technology software S00: RS flipflops
B9550
RS flipflop 1: Output Q FB 215 B210
B9551
RS flipflop 1: Output /Q FB 215 B210
B9552
RS flipflop 2: Output Q FB 216 B210
B9553
RS flipflop 2: Output /Q FB 216 B210
B9554
RS flipflop 3: Output Q FB 217 B210
B9555
RS flipflop 3: Output /Q FB 217 B210
B9556
RS flipflop 4: Output Q FB 218 B210
B9557
RS flipflop 4: Output /Q FB 218 B210
B9558
RS flipflop 5: Output Q FB 219 B210
