Connectors and binectors 05.05
12-58 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
Binector Name, description Function
diag., Sheet
B9559
RS flipflop 5: Output /Q FB 219 B210
B9560
RS flipflop 6: Output Q FB 220 B210
B9561
RS flipflop 6: Output /Q FB 220 B210
B9562
RS flipflop 7: Output Q FB 221 B210
B9563
RS flipflop 7: Output /Q FB 221 B210
B9564
RS flipflop 8: Output Q FB 222 B210
B9565
RS flipflop 8: Output /Q FB 222 B210
B9566
RS flipflop 9: Output Q FB 223 B210
B9567
RS flipflop 9: Output /Q FB 223 B210
B9568
RS flipflop 10: Output Q FB 224 B210
B9569
RS flipflop 10: Output /Q FB 224 B210
B9570
RS flipflop 11: Output Q FB 225 B210
B9571
RS flipflop 11: Output /Q FB 225 B210
B9572
RS flipflop 12: Output Q FB 226 B210
B9573
RS flipflop 12: Output /Q FB 226 B210
B9574
RS flipflop 13: Output Q FB 227 B210
B9575
RS flipflop 13: Output /Q FB 227 B210
B9576
RS flipflop 14: Output Q FB 228 B210
B9577
RS flipflop 14: Output /Q FB 228 B210
Technology software S00: Timers
B9580
Timer 1: Output FB 240 B215
B9581
Timer 1: Output inverted FB 240 B215
B9582
Timer 2: Output FB 241 B215
B9583
Timer 2: Output inverted FB 241 B215
B9584
Timer 3: Output FB 242 B215
B9585
Timer 3: Output inverted FB 242 B215
B9586
Timer 4: Output FB 243 B215
B9587
Timer 4: Output inverted FB 243 B215
B9588
Timer 5: Output FB 244 B215
B9589
Timer 5: Output inverted FB 244 B215
B9590
Timer 6: Output FB 245 B215
B9591
Timer 6: Output inverted FB 245 B215
B9592
Timer 7: Output FB 246 B216
B9593
Timer 7: Output inverted FB 246 B216
B9594
Timer 8: Output FB 247 B216
B9595
Timer 8: Output inverted FB 247 B216
B9596
Timer 9: Output FB 248 B216
B9597
Timer 9: Output inverted FB 248 B216
B9598
Timer 10: Output FB 249 B216
B9599
Timer 10: Output inverted FB 249 B216
Serial interface 3 (USS3 / Peer-to-peer 3 on G-SST3)
B9600
USS3 receive data, word 6, bit 0 G172
B9601
USS3 receive data, word 6, bit 1 G172
B9602
USS3 receive data, word 6, bit 2 G172
B9603
USS3 receive data, word 6, bit 3 G172
B9604
USS3 receive data, word 6, bit 4 G172
B9605
USS3 receive data, word 6, bit 5 G172
B9606
USS3 receive data, word 6, bit 6 G172
