05.05 Connectors and binectors
SIEMENS AG 6RX1700-0AD76 12-59
SIMOREG DC Master Operating Instructions
Binector Name, description Function
diag., Sheet
B9607
USS3 receive data, word 6, bit 7 G172
B9608
USS3 receive data, word 6, bit 8 G172
B9609
USS3 receive data, word 6, bit 9 G172
B9610
USS3 receive data, word 6, bit 10 G172
B9611
USS3 receive data, word 6, bit 11 G172
B9612
USS3 receive data, word 6, bit 12 G172
B9613
USS3 receive data, word 6, bit 13 G172
B9614
USS3 receive data, word 6, bit 14 G172
B9615
USS3 receive data, word 6, bit 15 G172
Technology software S00: PI controller [SW 1.8 and later]
B9650
PI controller 1: Controller at output limitation FB 260 B180
B9652
PI controller 3: Controller at output limitation FB 262 B182
B9653
PI controller 4: Controller at output limitation FB 263 B183
B9654
PI controller 5: Controller at output limitation FB 264 B184
B9655
PI controller 6: Controller at output limitation FB 265 B185
B9656
PI controller 7: Controller at output limitation FB 266 B186
B9657
PI controller 8: Controller at output limitation FB 267 B187
B9658
PI controller 9: Controller at output limitation FB 268 B188
B9659
PI controller 10: Controller at output limitation FB 269 B189
B9660
PI controller 1: Controller at positive output limitation FB 260 B180
B9661
PI controller 2: Controller at positive output limitation FB 261 B181
B9662
PI controller 3: Controller at positive output limitation FB 262 B182
B9663
PI controller 4: Controller at positive output limitation FB 263 B183
B9664
PI controller 5: Controller at positive output limitation FB 264 B184
B9665
PI controller 6: Controller at positive output limitation FB 265 B185
B9666
PI controller 7: Controller at positive output limitation FB 266 B186
B9667
PI controller 8: Controller at positive output limitation FB 267 B187
B9668
PI controller 9: Controller at positive output limitation FB 268 B188
B9669
PI controller 10: Controller at positive output limitation FB 269 B189
B9670
PI controller 1: Controller at negative output limitation FB 260 B180
B9671
PI controller 2: Controller at negative output limitation FB 261 B181
B9672
PI controller 3: Controller at negative output limitation FB 262 B182
B9673
PI controller 4: Controller at negative output limitation FB 263 B183
B9674
PI controller 5: Controller at negative output limitation FB 264 B184
B9675
PI controller 6: Controller at negative output limitation FB 265 B185
B9676
PI controller 7: Controller at negative output limitation FB 266 B186
B9677
PI controller 8: Controller at negative output limitation FB 267 B187
B9678
PI controller 9: Controller at negative output limitation FB 268 B188
B9679
PI controller 10: Controller at negative output limitation FB 269 B189
S00 technology software: Limit-value monitors for double-word connectors
B9680
Limit-value monitor 1: |A| < B has responded [SW 1.9 and later] FB 68 B151
B9681
Limit-value monitor 1: A < B has responded [SW 1.9 and later] FB 68 B151
B9682
Limit-value monitor 1: A = B has responded [SW 1.9 and later] FB 68 B151
B9683
Limit-value monitor 2: |A| < B has responded [SW 1.9 and later] FB 69 B151
B9684
Limit-value monitor 2: A < B has responded [SW 1.9 and later] FB 69 B151
B9685
Limit-value monitor 2: A = B has responded [SW 1.9 and later] FB 69 B151
