Siemens 7UT51

7UT51 v3
Settings Record
20
PRIM-2330C 219
2725
Tdly
-
TANK
Operating time delay of tank protection
0.00
-
60.00 s or ∞ 0.00
2727
Trst
-
TANK
Reset delay after trip has been initiated
0.00
-
60.00 s 0.10
2900
MEASURED VALUE SUPERVISION
Password level = 2
2903
SYM.Ithres
60
-
Symmetry threshold for current
monitoring
[Unit /I/In or A???]
0.10
-
1.00 I/In 0.50
2904
SYM.Fact.I
60
-
Symmetry factor for current monitoring
0.00
-
0.95 0.50
3000
INCLUSION OF AN EXTERNAL TRIP FUNCTION 1
Password level = 2
3001
EXT.TRIP 1
State of external trip function 1
OFF X
ON
Block Tripping
3002
Tdly
-
EXT1
Time delay of external trip function 1
0.00
-
60.00 s or ∞ 0.00
3003
Trst
-
EXT1
Reset delay after trip 1 has been initiated
0.00
-
60.00 s 0.10
3100
EXTERNAL TRIP FUNCTION 2
Password level = 2
3101
EXT.TRIP 2
State of external trip function 2
OFF X
ON
Block Tripping
3102
Tdly
-
EXT2
Time delay of external trip function 2
0.00
-
60.00 s or ∞ 0.00
3103
Trst
-
EXT2
Reset delay after trip 2 has been initiated
0.00
-
60.00 s 0.10
Addr
LCD Line 1
WinDIGSI Description
Options or
Range and Unit
Default
Setting
Group A
Setting
Group B
Setting
Group C
Setting
Group D
Addr LCD Line 1 Index Setting Index Setting
6100
DISCRETE INPUTS
Password level = 3
6101
DISCRETE
INPUT 1
001 0005 Reset LEDs HI 006
002 007
003 008
004 009
005 010
6102
DISCRETE
INPUT 2
001 2306 >Block 50HS stage of backup
O/C HI
006
002 007
003 008
004 009
005 010
6103
DISCRETE
INPUT 3
001 0011 >User defined event 1 HI 006
002 007
003 008
004 009
005 010
