Siemens 7UT51

20
Settings Record
7UT51 v3
220 PRIM-2330C
6104
DISCRETE
INPUT 4
001 0391 >Warning stage from Buchholz
prot. HI
006
002 007
003 008
004 009
005 010
6105
DISCRETE
INPUT 5
001 0392 >Tripping stage from Buchholz
prot. HI
006
002 007
003 008
004 009
005 010
6200
SIGNAL RELAYS
Password level = 3
Up to 20 functions per signal relay.
6201
SIGNAL RELAY 1 001 0511 General trip of the relay 006
002 007
003 008
004 009
005 010
6202
SIGNAL RELAY 2 001 5671 87
-
Diff protection: General trip 006
002 007
003 008
004 009
005 010
6203
SIGNAL RELAY 3 001 2451 BU Overcurrent+G/F : General Trip 006
002 007
003 008
004 009
005 010
6204
SIGNAL RELAY 4 001 0141 Failure of internal 24VDC power
supply
006 0152 Failure in I/O module 2
002 0143 Failure of internal 15VDC power
supply
007
003 0144 Failure of internal 50VDC power
supply
008
004 0145 Offset failure (A/D converter) 009
005 0151 Failure in I/O module 1 010
6205
SIGNAL RELAY 5 001 0051 Relay OK 006
002 007
003 008
004 009
005 010
6206
SIGNAL RELAY 6 001 1571 49
-
TRIP by thermal O/L protection
1
006
002 1621 49
-
TRIP by thermal O/L protection
2
007
003 008
004 009
005 010
6207
SIGNAL RELAY 7 001 1566 49
-
Thermal O/L prot.1: Thermal
warning
006
002 1616 49
-
Thermal O/L prot.2: Thermal
waning
007
003 008
004 009
005 010
Addr LCD Line 1 Index Setting Index Setting
