Siemens 7UT51

7UT51 v3
Settings Record
20
PRIM-2330C 221
6208
SIGNAL RELAY 8 001 5821 Restricted ground
-
fault: General
TRIP
006
002 007
003 008
004 009
005 010
6209
SIGNAL RELAY 9 001 5921 Transformer tank prot.: General
TRIP
006
002 007
003 008
004 009
005 010
6210
SIGNAL RELAY
10
001 0391 Warning stage from Buchholz
protection
006
002 007
003 008
004 009
005 010
6211
SIGNAL RELAY
11
001 0392 Tripping stage from Buchholz
protection
006
002 007
003 008
004 009
005 010
6300
LEDs
Password level = 3
Up to 20 functions to each LED.
6301
LED 1 001 0511 General trip of the relay m 006
002 007
003 008
004 009
005 010
6302
LED 2 001 5691 87
-
Diff protection: Trip m 006
002 007
003 008
004 009
005 010
6303
LED 3 001 5692 87HS
-
Diff protection: Trip m 006
002 007
003 008
004 009
005 010
6304
LED 4 001 2451 BU Overcurrent+G/F : General
Trip m
006
002 007
003 008
004 009
005 010
6305
LED 5 001 0141 Failure of internal 24VDC power
supply nm
006 0153 Failure in I/O module 2 nm
002 0143 Failure of internal 15VDC power
supply nm
007
003 0144 Failure of internal 50VDC power
supply nm
008
004 0145 Offset failure (A/D converter) nm 009
005 0151 Failure in I/O module 1 nm 010
Addr LCD Line 1 Index Setting Index Setting
