Siemens 7UT51

7UT51 v3
Settings Record
20
PRIM-2330C 223
6400
TRIP RELAYS
Password level = 3
6401
TRIP RELAY 1 001 5691 87
-
Diff protection: Trip 006 1571 49
-
TRIP by thermal O/L
protection 1
002 5692 87HS
-
Diff protection: Trip 007 1621 49
-
TRIP by thermal O/L
protection 2
003 2451 BU Overcurrent+G/F: General Trip 008
004 5821 Restrictd ground
-
fault: General
TRIP
009
005 5921 Transformer tank prot.: General
TRIP
010
6402
TRIP RELAY 2 001 5691 87
-
Diff protection: Trip 006 1571 49
-
TRIP by thermal O/L
protection 1
002 5692 87HS
-
Diff protection: Trip 007 1621 49
-
TRIP by thermal O/L
protection 2
003 2451 BU Overcurrent+G/F: General Trip 008
004 5821 Restrictd ground
-
fault: General
TRIP
009
005 5921 Transformer tank prot.: General
TRIP
010
6403
TRIP RELAY 3 001 5691 87
-
Diff protection: Trip 006 1571 49
-
TRIP by thermal O/L
protection 1
002 5692 87HS
-
Diff protection: Trip 007 1621 49
-
TRIP by thermal O/L
protection 2
003 2451 BU Overcurrent+G/F: General Trip 008
004 5821 Restrictd ground
-
fault: General
TRIP
009
005 5921 Transformer tank prot.: General
TRIP
010
6404
TRIP RELAY 4 001 5691 87
-
Diff protection: Trip 006 1571 49
-
TRIP by thermal O/L
protection 1
002 5692 87HS
-
Diff protection: Trip 007 1621 49
-
TRIP by thermal O/L
protection 2
003 2451 BU Overcurrent+G/F: General Trip 008
004 5821 Restrictd ground
-
fault: General
TRIP
009
005 5921 Transformer tank prot.: General
TRIP
010
6405
TRIP RELAY 5 001 5691 87
-
Diff protection: Trip 006 1571 49
-
TRIP by thermal O/L
protection 1
002 5692 87HS
-
Diff protection: Trip 007 1621 49
-
TRIP by thermal O/L
protection 2
003 2451 BU Overcurrent+G/F: General Trip 008
004 5821 Restrictd ground
-
fault: General
TRIP
009
005 5921 Transformer tank prot.: General
TRIP
010
Addr LCD Line 1 Index Setting Index Setting
