Siemens 7UT51

20
Settings Record
7UT51 v3
224 PRIM-2330C
Addr
LCD Line 1
WinDIGSI Description
Options or
Range and Unit
Default Setting
7100
LOCAL USER INTERFACE
Password level = 3, except password level = 4 to set addresses 7151 to 7154
7101
LANGUAGE
Language
German X
English
US
-
English
7102
DATE FORMAT
Date format
DD.MM.YY (Europe) X
MM/DD/YY (US)
7105
LINE 1 NORMAL
Top line of display under normal conditions
See
Table 13.1
0741
7106
LINE 2 NORMAL
Bottom line of display under normal conditions
See
Table 13.1
0744
7107
LINE 1 FAULT
Top line of display after a fault
See
Table 13.1
0543
7108
LINE 2 FAULT
Bottom line of display after a fault
See
Table 13.1
0544
7110
NEW TARGETS
Update LEDs/display (with pickup or with trip)
WITH PICKUP X
WITH TRIP
7200
CONFIGURATION OF COMM PORTS
Password level = 3
7201
DEVICE ADD
Device address
1
-
254 1
7202
FEEDER ADD
Feeder address
1
-
254 1
7203
STATION ADD
Substation address
1
-
254 1
7208
FUNCT. TYPE
Function type (for the VDEW
-
protocol)
1
-
254 160
7209
DEVICE TYPE
Device Type
1
-
254 35 Do Not Change
7211
FRONT PORT
Front port
WinDIGSI V3 X
ASCII
7215
FRONT BAUD
Baud rate for the front port
9600 BAUD X
19200 BAUD
1200 BAUD
2400 BAUD
4800 BAUD
7216
FRT. PARITY
Parity and stop
-
bits for the front port
WinDIGSI V3 X
NO PARITY,2 STOP
NO PARITY,1 STOP
7221
REAR PORT
Data format (protocol) for rear port
VDEW COMPATIBLE X
VDEW EXTENSION
WinDIGSI V3
LSA
7222
REAR FORMAT
Measured value format for the rear port
VDEW COMPATIBLE X
VDEW EXTENSION
7225
REAR BAUD
Baud rate of the rear port
9600 BAUD X
19200 BAUD
1200 BAUD
2400 BAUD
4800 BAUD
