Use WINPM.NET to clear each data log file, independently of the
others, from the meter’s memory. For instructions on setting up and
clearing data log files, refer to the
WINPM.NET online help file.
Table 8–5: Default Data Log 1 Register List
Description
Number of
Registers
Data Type➀ Register Number
Start Date/Time 3 D/T Current D/T
Current, Phase A 1 integer 1100
Current, Phase B 1 integer 1101
Current, Phase C 1 integer 1102
Current, Neutral 1 integer 1103
Voltage A-B 1 integer 1120
Voltage B-C 1 integer 1121
Voltage C-A 1 integer 1122
Voltage A-N 1 integer 1124
Voltage B-N 1 integer 1125
Voltage C-N 1 integer 1126
True Power Factor, Phase A 1 signed integer 1160
True Power Factor, Phase B 1 signed integer 1161
True Power Factor, Phase C 1 signed integer 1162
True Power Factor, Total 1 signed integer 1163
Last Demand, Current,
3-Phase Average
1 integer 2000
Last Demand, Real Power,
3-Phase Total
1 integer 2150
Last Demand, Reactive
Power, 3-Phase Total
1 integer 2165
Last Demand, Apparent
Power 3-Phase Total
1 integer 2180
➀ Refer to Appendix A for more information about data types.
