© 2008 Siemens Energy & Automation, Inc. All Rights Reserved
PMCM-9340D-0208 ACCESS 9340 and 9360 Meters
2/2008 Appendix C—EN50160 Evaluation
EN–229
All of the EN50160 data is stored in non-volatile memory once per
hour or when an event occurs. In the event of a meter reset, up to one
hour of routine meter evaluation data will be lost.
EN50160 Evaluation System Configuration and Status Registers
Table C–4 lists registers for system configuration and status
evaluation.
Table C–4: EN50160 Evaluation System Configuration and Status Registers
Register Number Description
3900 1
Enable/Disable EN50160 Evaluation
0 = Disable (default)
1 = Enable
3901 1
Nominal Voltage, (copied from register 3234 for reference)
Default = 230
3902 1
Voltage Selection for 4-Wire Systems
0 = Line-to-Neutral (default)
1 = Line-to-Line
3903 1
Nominal Frequency, Hz (copied from register 3208 for reference)
Default = 60
3904 1
Frequency configuration
0 = system with synchronous connection to interconnected system
(default)
1 = system without synchronous connection to interconnected system
3905 1
First Day of Week
1 = Sunday
2 = Monday (default)
3 = Tuesday
4 = Wednesday
5 = Thursday
6 = Friday
7 = Saturday
3906 1
Definition of Interruption
0 – 10% Nominal (default = 1)
3907 1
Allowable Range of Slow Voltage Variations
1 – 20% Nominal (default = 10)
3908 1
Reserved
3909 1
Reserved
