Siemens PFA-100 System - Keyboard; Printer

PFA-100 System – Instruction Manual (US) – Version 1.0.1
46
6 Description of the analyzer
6
Contrast adjustment The contrast adjustment button is located on the back side of the analyzer,
between the Software Upgrade Slot and the External PC Port. By rotating
this button, the analyzer display can be set to the desired contrast.
6.1.4 Keyboard
The keyboard is composed of two types of keys (See Figure 6-4.): The
numeric keys and the softkeys. The setup allows the user to select an
audible tone to sound when pressing the keys.
6.1.5 Printer
The printer is located on top of the analyzer. A small cartridge ribbon allows
printing of the data on any standard 58mm wide plain paper.
Figure 6-4 LCD display and keyboard
LCD display
Softkeys
Numeric keys
Platelet Function Analyzer
Figure 6-5 Printer and printer paper slot
1
2
3
4
7
8
9
<
.
0
5
6
Printer
Platelet Function Analyzer
