6 Description of the analyzer
PFA-100 System – Instruction Manual (US) – Version 1.0.1
76
6.2.3 PFA test cartridges
Detailed descriptions of the PFA test cartridges, their handling and their
applications are provided in the instructions for use of each PFA test
cartridge type. Refer to the according instructions for use for more
information.
6.3 Technical specifications
6.3.1 Physical
6.3.2 Electrical
Parameter Value
Dimensions (L x W x H) 38.4cm x 22.9cm x 36cm
(15.1" x 9" x 14.2")
Weight 10.9kg (24lbs.)
Over-voltage will result in damage to the instrument.
Make sure that the main supply voltage does not exceed the recommended
ranges.
Parameter Value
Operating voltage/frequency 100VAC - 240VAC, 60Hz
200VAC - 240 VAC, 50Hz
Current (maximum) 1.5A/100VAC, 0.75A/200VAC
Power consumption (maximum) 110W
Fuse Slo-Blo fuse, Littelfuse, 250V, 1.5A
