From above
Figure 10-17 Top of the housing
Grounding bolts pressed in (100 to 240 VAC / 60 to 250 VDC)
Figure 10-18 Example of a XR324-4M EEC (2 x 100 to 240 VAC, cable outlet front)
Graphics
10.5 XR-300M EEC dimension drawings
SCALANCE X-300
234 Operating Instructions, 11/2019, A5E01113043-24
