Standard Functions
12.7 Safety Oriented Tripping
SIMOCODE PRO V PN FDI
Programming and Operating Manual, 05/2020, A5E44499659002A/RS-AA/001
101
Settings of the DIP switches, DM-F PROFIsafe
Set the PROFIsafe address using the DIP switches on the DM-F PROFIsafe as follows:
When one DIP switch is set to ON, the respective value is active. When more than one DIP
switch is set to ON, the respective values must be added up.
"Safe tripping" response 1)
Here, you set the SIMOCODE pro reaction to a safety-oriented tripping via the DM-F Local
or the DM-F PROFIsafe.
Note
The module response is not affected by this setting. In the event of the conditions for
safety-
oriented tripping being fulfilled, the enabling circuits are always opened!
Note
In the event that the option "DM
-F LOCAL/PROFIsafe - separate function from control
has been activated under "Motor control > Control function > Operating mode",
"Safe Tripping" can no longer be set as response; "Deactivated", "Send" or "Warning" are
the only remaining options.
