Siemens SIMOCODE 3UF - Cyclic Send Data Byte 0; Cyclic Send Data Byte 1; Cyclic Send Data Byte 2-3 (4-9)

Outputs
11.7 Cyclic Send Data
SIMOCODE PRO V PN FDI
84 Programming and Operating Manual, 05/2020, A5E44499659002A/RS-AA/001
11.7.2 Cyclic Send Data Byte 0
Cyclic Send Data Byte 0
Byte 0, Bit 0 to Bit 7, Basic types 1*, 2: Controls of the bits with any signals(any sockets, e.g.
Device Inputs, Send Data, etc.).
*) For Basic Unit 2 only
11.7.3 Cyclic Send Data Byte 1
Cyclic Send Data Byte 1
Byte 1, Bit 0 to Bit 7, Basic types 1*, 2: Controls of the bits with any signals (any sockets,
e.g. Device Inputs, Send Data, etc.).
*) For Basic Unit 2 only.
11.7.4 Cyclic Send Data Byte 2-3 (4-9)
Cyclic Send Data Byte 2-3 (4-9)
Byte 2/3 Basic types 1 *), 2: Control of 1 word (2 bytes) with any analog values (any sockets
e.g. maximum current I_max, remaining cooling time, actual value of timers, etc.).
Byte 4/5, 6/7, 8/9 Basic type 1 *): Control of 3 words (6 bytes) with any analog values (any
sockets).
*) For Basic Unit 2 only.
Note
Active power Pa signed and active powe
r Pb signed (Inverted) for cyclic bytes (6-13) with
float values is not supported with current / voltage measuring module V2 configured with
SIMOCODE pro V PB 4.1.
