Logic Modules
13.4 Signal Conditioner
SIMOCODE PRO V PN FDI
Programming and Operating Manual, 05/2020, A5E44499659002A/RS-AA/001
121
13.3.2 Timer 1-6
Timer 1-6
Type
Different Output Responses.
Range: closing delay
, closing delay with memory, closing delay with fleeting
closing
Limit
Time during which the Timer provides an output signal when activated, depending
on the output response (type).
Range: 0 to 65535, unit 100 ms
Input
Activation by any signal (any sockets, e.g. device inputs, control bits from
PROFINET, etc.)
Reset
Resets the actual value to 0.
Activation by any signal (any sockets, e.g. device inputs, control bits from
PROFINET, etc.)
13.4 Signal Conditioner
13.4.1 Signal Conditioner
Signal Conditioner
If an input signal is pending, the Signal Conditioner can issue an output signal according to
the chosen Timer type:
● Non Inverting
● Inverting
● Edge rising with memory
● Edge falling with memory.
You can set the output response.
The Signal Conditioner consists of:
● 2 plugs (input and reset)
● 1 logic component
● 1 socket (Signal Conditioner Output).
In total, 6 signal conditioners (1 to 6) for the SIMOCODE pro V PN basic unit are available.
Note
The Output is always 0 if a Reset is pending.
