Outputs
11.4 Digital Module 2 Outputs
SIMOCODE PRO V PN FDI
78 Programming and Operating Manual, 05/2020, A5E44499659002A/RS-AA/001
Application examples
Controlling the motor contactor in the motor feeder:
You can e.g. define which relay output is used for controlling the motor contactor in the
motor feeder. For this, connect the desired relay output to the respective "QE" contactor
control of the control function.
Lamp control for displaying operating states:
You can e.g. define which relay outputs are to be used for controlling the lamps/LEDs
displaying operating states of the motor (FAULT, ON, OFF, FAST, SLOW...).
For this, connect the desired relay output to the respective "QE..." Lamp Control of the
control function.
Transfer of any other information, status information, warnings, faults, etc. to the relay
outputs.
Settings Digital Module 1 Outputs
Control of the DM1 outputs function block with any signal (any sockets, e.g. device inputs,
control bits from PROFINET, etc. usually from the QE contactor controls).
11.4 Digital Module 2 Outputs
Digital Module 2 Outputs
SIMOCODE pro has a DM2 Outputs function block, which is equipped with two Relay
Outputs. You can e.g. switch contactors or lamps via these Relay Outputs. For this, the
inputs (plugs of the DM2 Outputs function block) must be connected to the respective
sockets (e.g. of the control function).
The DM2 Outputs function block has:
2 plugs, corresponding to the relay outputs Out1, Out2.
2 relays.
Output terminals.
Note
In addition to the two jointly
-switched failsafe enabling circuits, the failsafe DM-F Local and
DM
-F
PROFIsafe digital modules are equipped with two standard relay outputs, the common
root of which is switched off for safety reasons via an enabling circuit.
For the logical wiring, the standard relay outputs are always switched. The state of the
failsafe e
nabling circuits is not affected by the logical wiring.
