Standard Functions
12.7 Safety Oriented Tripping
SIMOCODE PRO V PN FDI
102 Programming and Operating Manual, 05/2020, A5E44499659002A/RS-AA/001
Reset "Safe tripping"
Here, you can select manual or automatic acknowledging of SIMOCODE pro faults caused
by safety-oriented tripping (default: manual).
12.7.2 DM-F LOCAL Digital Module
DM-F LOCAL Digital Module
The "DM-F Local safe tripping" function block consists of 3 sockets:
● Event - DM-F LOCAL ok: The DM-F Local is ready for operation.
● Event - Safe tripping: A safety-oriented tripping has been carried out.
● Status - Enabling circuit closed: The enabling circuit is closed.
Settings of the DIP switches, DM-F Local
-switch position in the Device Integration Manager user interface (which can be
done using the mouse pointer) is transferred to the basic unit as part of the standard
download. However, it does not affect the function of the DM
-F Local.
This way, the desired function is already
set during parameterization.
The effective parameterization must be set using the DIP switches on the front of the DM
-F
Local (see table below and/or "Failsafe Digital Modules SIMOCODE pro Safety Solutions"
manual).
The basic unit compares the set position
(from the download) with the actual position at the
-F Local. If these differ "Configuration deviation" is output!
