Logic Modules
13.2 Counter
SIMOCODE PRO V PN FDI
Programming and Operating Manual, 05/2020, A5E44499659002A/RS-AA/001
119
In total, 6 counters (1 to 6) for the SIMOCODE pro V PN basic unit are available.
Note
The time between the events to be counted depends on:
•
the input delay
•
the device cycle time.
Note
The actual value
remains the same:
•
during parameterization or failure of the supply voltage
•
if there are simultaneous input signals at Input + and Input -.
Note
The output is always 0 if a reset is pending.
13.2.2 Counter 1-6
Counter 1-6
Limit
The maximum value that
can be reached when counting and where
the counter issues an output signal.
Range: 0 - 65535
Input +
Increases the actual value by 1.
Activation by any signal (any sockets e.g. device inputs, control bits
from PROFINET, etc.
Input
-
Decreases the actual
value by 1.
Activation by any signal (any sockets e.g. device inputs, control bits
from PROFINET, etc.
Reset
Resets the Counter to 0 (count value and output).
Activation by any signal (any sockets e.g. device inputs, control bits
from PROFINET, etc.)
