Online Settings and Displays
17.3 Actual Configuration/HW-Diagnostics
SIMOCODE PRO V PN FDI
Programming and Operating Manual, 05/2020, A5E44499659002A/RS-AA/001
145
17.3 Actual Configuration/HW-Diagnostics
17.3.1 Actual Configuration/HW-Diagnostic
Actual Configuration/HW-Diagnostic
See Actual Configuration (Page 145)
See HW-Diagnostic (Page 145)
17.3.2 Actual Configuration
Actual Configuration
In dialogue "Actual Configuration" the existing configuration can be read if a connection has
already been established via SIMOCODE pro.
Symbol
Description
ok
Module available and operational
not available Module not available
In the case of DM1 = DM-F Local, the actual DIP switch position from data record 105 (see
System Manual SIMOCODE pro) is shown in "Modules" and the DIP switch position from
data record 130 (see System Manual SIMOCODE pro) is shown in "Parameterized
Configuration". The meaning of the individual DIP switches is as follows: See Safety-oriented
tripping.
17.3.3 HW-Diagnostic
HW-Diagnostic
In dialogue "HW-Diagnostic" you can verify if the projected device configuration matches the
real device configuration:
Symbol
Description
ok
Module available and operational
faulty
Module faulty
In the case of DM1 = DM-F Local or DM-F PROFIsafe the actual DIP switch position from
data record 105 (see System Manual SIMOCODE pro) is shown in "Modules" and the DIP
switch position from data record 130 (see System Manual SIMOCODE pro) is shown in
"Parameterized Configuration". The meaning of the individual DIP switches is as follows:
See Safety-oriented tripping.
