Siemens SIMOCODE 3UF User Manual

Logic Modules
13.5 Non-volatile Element
SIMOCODE PRO V PN FDI
122 Programming and Operating Manual, 05/2020, A5E44499659002A/RS-AA/001
13.4.2 Signal Conditioner 1-6
Signal Conditioner 1-6
Type Different output responses.
Range:
Level not inverted
, level inverted, edge rising with memory, edge falling with
memory
Input Activation by any signal (any sockets, e.g. device inputs, control bits from
PROFINET, etc.)
Reset Resets the Signal Conditioner to 0. Activation by any signal (any sockets, e.g.
device inputs, control bits from PROFINET, etc.)
13.5 Non-volatile Element
13.5.1 Non-volatile Element
Non-volatile Element
Non-Volatile Elements behave like Signal Conditioners. The output signals remain after
failure of the supply voltage.
If an input signal is pending, the signal conditioner can issue an output signal according to
the type of Signal Conditioner chosen:
● Non Inverting
● Inverting
● Edge rising with memory
● Edge falling with memory.
You can set the output response.
The Non-Volatile Element consists of:
● 2 plugs (input and reset)
● 1 logic component
● 1 socket (Non-volatile Element Output).
In total, 4 non-volatile elements (1 to 4) for the SIMOCODE pro V PN basic unit are
available.
Note
The
output is always 0 if a reset is pending.
