Motor Control
8.2 Control Station
SIMOCODE PRO V PN FDI
34 Programming and Operating Manual, 05/2020, A5E44499659002A/RS-AA/001
8.2.5 PC - OPC-UA [HMI]
PC - OPC-UA [HMI]
This control station is primarily intended for switching commands on an arbitrary PC that,
along with the automation system, is used as a second master on PROFINET or that, as a
client, accesses the data made available by SIMOCODE pro, as server, via OPC-UA. The
control commands are transferred using a client-server connection via OPC-UA.
Note
If the SIMOCODE ES Professional or Device Integration Manager is connected to
SIMOCODE pro via PROFINET, its control commands automatically take effect via the
"PC/OPC
-UA" control station.
At the same time, the enabled commands for this control station also take effect for
SIMOCODE ES.
8.2.6 Operator Panel [OP]
Operator Panel [OP]
This control station is primarily intended for control commands issued via the buttons of the
3UF72 Operator Panel which is e.g. mounted in a switchgear cabinet door. The plugs of the
Control Stations function block must be connected to arbitrary sockets (normally with the
function block for the buttons of the Operator Panel - OP Buttons) for the control commands
to take effect.
Note
Since the operator panel only has four buttons for controlling the motor feeder, one button
must be used as a speed switch
button for control functions with two rotational speeds and
two directions for rotation.
For this purpose, the button must be assigned to the internal control command "[OP] <>/
<<>>".
