Inputs
10.2 Analog Module Inputs
SIMOCODE PRO V PN FDI
Programming and Operating Manual, 05/2020, A5E44499659002A/RS-AA/001
71
Digital Module - delay time inputs
If necessary, you can set a delay time for the inputs. Range: 6, 16, 26, 36 ms.
These values are valid for digital modules with a 24 V DC input supply.
For digital modules with a 110 to 240 V AC/DC input supply, the values are about 40 ms
higher.
Note
The delay times of the digital module inputs can only be set and/or are only relevan
t when
"monostable" or "bistable" is set for digital module 1.
The delay time cannot be set if digital module 1 is a DM
-F PROFIsafe.
If digital module 1 is a DM
-F Local, the delay times can be set using the DIP switches on the
-F Local.
10.2 Analog Module Inputs
Analog Module Inputs
SIMOCODE pro has 2 AM Inputs function blocks (AM1 Inputs and AM2 Inputs) (AM2 inputs
only in connection with SIMOCODE pro V PN basic unit) with two analog sockets,
corresponding to the 2 analog inputs of the Analog Module. The effective analog value of
each Input can be read from these sockets and processed internally.
An additional binary socket of the function block represents the status of the sensor
measuring circuits. The analog values can be processed internally and/or transmitted
cyclically to the automation system via the Cyclic Send function blocks.
Note
The AM1/AM2 Inputs function blocks can only be used if the corresponding analog modules
(AM1 and/or AM2) have been connected and configured in the
device configuration!
Application examples
Typical applications are e.g.:
● Fill-level monitoring for implementing dry running protection for pumps.
● Monitoring of pollution in a filter using a differential pressure transducer.
