Siemens SIMOCODE 3UF User Manual

Standard Functions
12.7 Safety Oriented Tripping
SIMOCODE PRO V PN FDI
Programming and Operating Manual, 05/2020, A5E44499659002A/RS-AA/001
97
12.7 Safety Oriented Tripping
12.7.1 Safety-oriented Tripping
Safety-oriented Tripping
Note
Please note that the information made available for further processing is in the form of non
-
safety
-oriented signals.
Note
Please note that the "Safe tripping" function
block is not a safety-oriented tripping function.
The DM
-F Local safety function is determined by the DIP switch setting on the module only.
The DM
-F PROFIsafe safety function is performed by the failsafe program in the F-CPU.
Further information: See System Manual.
A total of 1 "Safe tripping" function block is available for SAFETY (Local) or PROFIsafe.
The "DM-F Local safe tripping" function block consists of 3 sockets:
● Event - DM-F LOCAL ok: The DM-F Local is ready for operation.
● Event - Safe tripping: A safety-oriented tripping has been carried out.
● Status - Enabling circuit closed: The enabling circuit is closed.
