Online Settings and Displays
17.15 Device - Trend
SIMOCODE PRO V PN FDI
168 Programming and Operating Manual, 05/2020, A5E44499659002A/RS-AA/001
17.15 Device - Trend
Device - Trend
With the menu command Device > Trend you can:
● Display the progress of the various measured values once you have already established
a connection with SIMOCODE pro. A minimum of one and a maximum of five measured
values can be selected.
● Display the level change of up to any five binary signals (sockets/plugs) of SIMOCODE
pro. Binary inputs and outputs can be displayed.
17.16 Trend - Settings
Trend - Settings
In the menu Trend > Settings you can select the measured values that you would like to see
in the trend dialog. To do so, check the relevant checkboxes.
Note
Once five measured values have been activated the remaining selection options are
disabled. It is not possible to select another measured value until one of the checkboxes has
been deactivated again.
17.17 Trend - Trend
Trend - Trend
In the menu Trend > Trend the measured curves for the selected measured values are
displayed. The various setting options for measured curves and the meaning of the
checkboxes are described in the operating manual "PCS 7 Process Control System - Device
Integration Manager".
