Online Settings and Displays
17.7 Control - Status Information
SIMOCODE PRO V PN FDI
Programming and Operating Manual, 05/2020, A5E44499659002A/RS-AA/001
151
-6 - actual value
Counter 1-6 - actual value
- Parameters at Statistical Data online menu are read-only if “Motor is in
operation” or “Feedback On” is set to 1.
17.7 Control - Status Information
Control - Status Information
In the section "Control/Status Information", you can initiate the following operations in the
"Control" field:
● Control the branch via "ON<<, ON<, OFF, ON>, ON>>".
The number of buttons depends on the control function chosen. The buttons are not
necessary for overload relays; only "OFF" and "ON" are shown for direct starters. This
functionality matches that of an operator panel. Thus, the operator panel must be
activated for operator enable.
The buttons are only active if:
– when connecting via the system interface the operating clearances for the operator
panel [OP] are set.
– when connecting via PROFINET the operating clearances for PC/OPC-UA are set.
● Acknowledges faults with "Reset" and switch the device back to operation readiness.
● Start a hardware test with "Test".
The different messages are displayed in the "Status" field by checkboxes.
