Inputs
10.3 Temperature Module Inputs
SIMOCODE PRO V PN FDI
72 Programming and Operating Manual, 05/2020, A5E44499659002A/RS-AA/001
Settings Analog Module - Inputs
Settings Analog Module - Inputs
Input Signal
0-20 mA
, 4-20 mA
Response at Open Circuit
Signaling, Warning, Tripping
Active Inputs
1 Input, 2 Inputs
Note
The value of the Analog Module Inputs is in S7 format.
Note
The Inputs of the
Analog Module are passive inputs i.e. to configure an Analog Input Circuit,
each Input will require an additional potential
-free external current source connected in
series. If the Output of the Analog Module is not being used by another application, it ca
n be
used as current source for an Input Circuit of the Analog Module. The "Start Value of Value
Range" and the "End Value of Value Range" of the Analog Module Output have to be set to
65535 for this. Thus, the maximum possible current will always be avail
able via the Analog
Module Output.
10.3 Temperature Module Inputs
Temperature Module Inputs
SIMOCODE pro has two TM Inputs function blocks (TM1 Inputs and TM2 Inputs) (TM2
inputs only in connection with SIMOCODE pro V PN basic unit) with three analog sockets
corresponding to the three sensor measuring circuits of the Temperature Module. The
temperature (in K) of the three measuring circuits can be read from these sockets and
processed internally. An additional analog socket always supplies the maximum temperature
of all three measured temperatures. Furthermore, the two binary sockets of the function
block represent the status of the sensor measuring circuits. The temperatures can be
processed internally and/or transmitted to the automation system via the Cyclic Send
function block.
Note
The TM1/TM2 Inputs function blocks can only be used if the corresponding temperature
modules (TM1 and/or TM2) have been connected and configured in the device configuration!
Notes on wiring:
You can connect up to three 2-wire or 3-wire temperature sensors.
