Online Settings and Displays
17.10 Faults
SIMOCODE PRO V PN FDI
156 Programming and Operating Manual, 05/2020, A5E44499659002A/RS-AA/001
Safety engineering
Meaning/Possible cause/Acknowledgement/Error processing
DM-F - Safety-oriented tripping The DM-F has tripped the enabling circuit for safety reasons.
The motor can only be switched on again after the DM-F
module enabling circuits have been closed.
Acknowledge with "Reset", if auto-reset is not active.
Further Information: See Safety-oriented tripping.
DM-F - Wiring DM-F module wiring fault (short-circuit to ground in the sensor
circuit / feedback circuit).
Please check the sensor circuit / feedback circuit wiring and
rectify the fault.
Acknowledge with "Reset".
Further Information: See Safety-oriented tripping.
DM-FL - Cross circuit DM-F Local sensor circuit cross circuit.
Please check the wiring of the two sensor circuits for cross
circuiting and rectify the fault.
Acknowledge with "Reset".
Further Information: See Safety-oriented tripping.
Monitoring
Meaning/Possible cause/Acknowledgement/Error processing
Trip level I> The maximum current has overshot the trip level.
Check the application which is driven by the motor.
Further information: Current limits I> (upper level).
Trip level I< The maximum current has undershot the trip level.
Check the application which is driven by the motor.
Further information: Current Limits I< (lower level).
Internal Earth Fault The internal earth-fault monitoring has been activated.
A fault current of too high a value is flowing.
Please check the motor connection cable for damage.
Acknowledge with "Reset".
Further information: Internal Earth fault.
External Earth Fault The external earth-fault monitoring has been activated.
A fault current of too high a value is flowing.
Check the motor connection cable for damage.
Acknowledge with "Reset".
Further information: External Earth fault.
