Monitoring Functions
9.8 Temperature
SIMOCODE PRO V PN FDI
66 Programming and Operating Manual, 05/2020, A5E44499659002A/RS-AA/001
Temperature
Description
Response Warning Level T>
Set response when the temperature is overshot (see the
following table "response")
Marking Warning Level T>
No parameters. Optional marking for designating the
signal, e.g. "Temperature >". Range: up to 10 characters
Hysteresis
0 to 255°C in 1°C increments (preset: 5°C)
Trip level and warning level activity
The trip level/warning level always takes effect, independent of whether the motor is running
or not (operating status "ON").
Response
Overtemperature: Here you can select how SIMOCODE pro should respond when the
temperature has overshot the warning level/trip level.
Response
Trip level T>
Warning level T>
Disabled
-
X
Signaling
X
X
Warning
-
X
Tripping
X
-
Note
With
motors for EEx e applications, the response must remain set to "Tripping"!
Note
The sensor type, the number of measuring circuits in use and the response to a sensor fault
must be set in the Temperature Module Inputs (TM Inputs) function block if
temperature
monitoring is being used.
Note
To monitor several sensor measuring circuits individually and independently, a suitable
number of free Limit Monitors can be linked to the Temperature Module Inputs function block
and differing limits set for
the individual temperature sensors.
