SIMPRO-100
Modbus
™
RTU Communications Protocol
C
PRIM-2400C 171
USER MAP ADDRESSES
00D0 User Map Address # 1
00D1 User Map Address # 2
00D2 User Map Address # 3
014A User Map Address # 123
014B User Map Address # 124
014C User Map Address # 125
014D Reserved
014E Reserved
014F Reserved
RELAY ELEMENTS
0150 Latched Targets, Row 1
0151 Rows 2, 3
0152 Rows 4, 5
0153 Rows 6, 7
0154 Rows 8, 9
0155 Rows 10, 11
0156 – 015F Reserved
RELAY STATUS
0160 Status Register 1 0 2047
0161 Status Register 2 0 511
0162 – 016F Reserved
INSTANTANEOUS METERING
0170 Ia Current 0 65535 1
0171 Ib Current 0 65535 1
0172 Ic Current 0 65535 1
0173 Average Current 0 65535 1
0174 In Current 0 65535 1
0175 Vab Voltage 0 if no voltage option 0 65535 1
0176 Vbc Voltage 0 if no voltage option 0 65535 1
0177 Vca Voltage 0 if no voltage option 0 65535 1
0178 Average Voltage 0 if no voltage option 0 65535 1
0179 Ia Rms Current 0 65535 1
017A Ib Rms Current 0 65535 1
017B Ic Rms Current 0 65535 1
017C Average Rms Current 0 65535 1
017D In Rms Current 0 65535 1
017E Vab Rms Voltage 0 if no voltage option 0 65535 1
017F Vbc Rms Voltage 0 if no voltage option 0 65535 1
Address
(hex)
Field Sample Low High Step Type
