Siemens SIMPRO-100 - Page 187

SIMPRO-100
Modbus
™
RTU Communications Protocol
C
PRIM-2400C 185
037A
037B
037C
037D
037E
037F
0380
0381
0382 Ia 0 65535 1
0383 Ib 0 65535 1
0384 Ic 0 65535 1
0385 In 0 65535 1
0386 Ig 0 65535 1
0387 3I2 0 65535 1
0388 Hottest Winding RTD See Note 1 See Note 3 See Note 3 1
0389 Hottest Bearing RTD See Note 1 See Note 3 See Note 3 1
038A Ambient RTD See Note 1 See Note 3 See Note 3 1
038B Hottest Other RTD See Note 1 See Note 3 See Note 3 1
038C Vab 0 if no voltage option 0 65535 1
038D Vbc 0 if no voltage option 0 65535 1
038E Vca 0 if no voltage option 0 65535 1
038F kW 0 if no voltage option -32768 32767 1
0390 kVAR 0 if no voltage option -32768 32767 1
0391 kVA 0 if no voltage option -32768 32767 1
0392 Power Factor 0 if no voltage option -100 100 1 • 0.01
0393 Frequency 2000 7000 1 • 0.01
0394 % Thermal Cap 0 65535 1 • 0.1
0395 % Unbalance Current 0 1000 1 • 0.1
0396 – 039F Reserved
EVENT RECORDS
03A0 Number of Event Records 0 14 1
03A1 Event Selection 1 14 1
03A2 Channel Selection 1 14 1
03A3 1/4 Cycle -32768 32767 1
03A4 2/4 Cycle -32768 32767 1
03A5 3/4 Cycle -32768 32767 1
03A6 1 Cycle -32768 32767 1
03A7 1 1/4 Cycle -32768 32767 1
03A8 1 2/4 Cycle -32768 32767 1
Address
(hex)
Field Sample Low High Step Type
