Table C.19 Modbus Register Map
Note 1: Summary RTD Temperature Addresses
can contain the following diagnostic
codes:
7ffeh = Fail
7ff0h = Not Attached or Not
Available
Note 2: Individual RTD Temperature Addresses
can contain the following diagnostic
codes:
8000h = RTD shorted
7fffh = RTD open
7ffch = SIMPRO-100-RTD
Communication Failure
7ff8h = SIMPRO-100-RTD
Self-Test Status Failure
7ff0h = RTD Not Attached or Not
Available
Note 3: RTD Temperature Range Depends on
the relay temperature preference
setting.
Note 4: The event type is reported as a
character string as shown in the table
below:
03D0 11 2/4 Cycle -32768 32767 1
03D1 11 3/4 Cycle -32768 32767 1
03D2 12 Cycle -32768 32767 1
03D3 12 1/4 Cycle -32768 32767 1
03D4 12 2/4 Cycle -32768 32767 1
03D5 12 3/4 Cycle -32768 32767 1
03D6 13 Cycle -32768 32767 1
03D7 13 1/4 Cycle -32768 32767 1
03D8 13 2/4 Cycle -32768 32767 1
03D9 13 3/4 Cycle -32768 32767 1
03DA 14 Cycle -32768 32767 1
03DB 14 1/4 Cycle -32768 32767 1
03DC 14 2/4 Cycle -32768 32767 1
03DD 14 3/4 Cycle -32768 32767 1
03DE 15 Cycle -32768 32767 1
03DF Reserved
Address
(hex)
Field Sample Low High Step Type
Temperature
Preference
Low High
°C -50 250
°F -58 482
Event Type Strings
Thermal Trip
Locked Rotor Trip
Load Loss Trip
Load Jam Trip
Current Unbalance Trip
Phase Fault Trip
Ground Fault Trip
Speed Switch Trip
