SIMPRO-100 Relay Settings Sheets
SIMPRO-100
214 PRIM-2400C
F.1.2 Thermal Model Elements
(Hidden when SETMETH = GENERIC
or USER
)
Setting Method
Range: Rating, Generic, User
SETMETH =
[RATING]
F.1.2.1 Thermal Element Settings When
Setting Method = Rating
(Hidden when SETMETH = RATING or USER)
Full Load Amps
Range: 2.50 – 8.00 A; ITAP = 5 A
0.50 – 1.60 A; ITAP = 1 A
FLA =
[5.00]
Service Factor
Range: 1.00 – 1.50
SF =
[1.15]
Locked Rotor Amps
Range: 7.50 – 80.00 A; ITAP = 5 A
Range: 2.50 – 16.00 A; ITAP = 1 A
LRA =
[30.00]
Hot Locked Rotor Time
Range: 1.0 – 200.0 s
LRTHOT =
[2.1]
Cold Locked Rotor Time
Range: 1.0 – 240.0 s
LRTCOLD =
[2.5]
Locked Rotor Trip Time Dial
Range: 0.10 – 1.50
TD =
[1.00]
F.1.2.2 Thermal Element Settings when
Setting Method = GENERIC
(Hidden when SETMETH = RATING or
GENERIC)
Full Load Amps
Range: 2.50 – 8.00 A; ITAP = 5 A
Range: 0.50 – 1.60 A; ITAP = 1 A
FLA =
[5.00]
Service Factor
Range: 1.00 – 1.50
SF =
[1.15]
Curve Number
Range: 1 – 45
CURVE =
[Hidden]
F.1.2.3 Thermal Element Settings when
Setting Method = USER
(Hidden when SETMETH = RATING or
GENERIC)
Full Load Amps
Range: 2.50 – 8.00 A; ITAP = 5 A
Range: 0.50 – 1.60 A; ITAP = 1 A
FLA =
[5.00]
Service Factor
Range: 1.00 – 1.50
SF =
[1.15]
Time to Trip at 1.05 x FLA
Range: 1.0 – 6000.0 s, NP
TTT105 =
[Hidden]
Time to Trip at 1.10 x FLA
Range: 1.0 – 6000.0 s, NP
TTT110 =
[Hidden]
Time to Trip at 1.20 x FLA
Range: 1.0 – 6000.0 s, NP
TTT120 =
[Hidden]
